Model Image
Manufacturer

Whirlpool

Model Number

LT7004XTW1

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
PT220L PT220L 4` 30 AMP 3 WIRE DRYER CORD
PT600L PT600L 6` 30 AMP 4 WIRE DRYER CORD
285666 285666 ACCESSORY PARTS, 8' DRAIN HOSE W/CLAMP
WP359807 WP359807 ACTUATOR
WP3349578 WP3349578 AGITATOR
WP72107 WP72107 ALMOND
350956 350956 ALMOND
978883 978883 ALMOND (UNCUT)
W10518375 W10518375 ASSEMBLY, DRUM
279982 279982 BAFFLE-DRM
3390026 3390026 BASE, DRYER
WP3402724 WP3402724 BASE-WASHR
3352234 3352234 BASKET & BALANCE RING ASSEMBLY
W10820043 W10820043 BASKTDRIVE
WP8546462 WP8546462 BEARING
285205 285205 BEARING
WP8546455 WP8546455 BEARING
WP21258 WP21258 BEARING
WP3387242 WP3387242 BEARING & SEAL
661570 661570 BELT
WP3362952 WP3362952 BEZEL
WP62505 WP62505 BLOCK, DISCONNECT (MOTOR 2 SPEED) (USE TERM. 352088)
WP389140 WP389140 BLOCK, DRIVE
279320 279320 BLOCK-TERM
W10802681 W10802681 BOX
3350744 3350744 BRACE
3349767 3349767 BRACKET
WPW10547294 WPW10547294 BRACKET
3388857 3388857 BRACKET, BASE
3391639 3391639 BRACKET, BULKHEAD
3390689 3390689 BRACKET, CONTROL (INCLUDES ILLUS. 2)
3389648 3389648 BRACKET, HEATER BOX
3389453 3389453 BRACKET, HINGE (2)
3350144 3350144 BRACKET, LID SWITCH
W11107903 W11107903 BRACKET, MOTOR
3354020 3354020 BRACKET, MOUNTING
WP64067 WP64067 BRACKET, SPRING DISPENSER OUTER (2)
WP64065 WP64065 BRACKET, SPRING OUTER (L.F.)
3390045 3390045 BRACKET, TERMINAL BLOCK
3349673 3349673 BRACKET, VALVE
279457 279457 BRACKET-FRONT FRAME SUPPORT (2 REQ)
WP3360977 WP3360977 BREAK-VAC
WP697557 WP697557 BULKHEAD
W11299300 W11299300 BULKHEAD
WP9724509 WP9724509 BUMPER
WP3389431 WP3389431 BUMPER
3389432 3389432 BUMPER, LID (ALMOND)
3389435 3389435 BUMPER, LID (GOLDEN WHEAT)
3389434 3389434 BUMPER, LID (PLATINUM)
3389433 3389433 BUMPER, LID (TOAST)
WP694419 WP694419 BUZZER
WP8546461 WP8546461 CAM-BRAKE
285550 285550 CAP
WP3355758 WP3355758 CAP
WP62646 WP62646 CAP
WP8572717 WP8572717 CAPACITOR
279570 279570 CATCH, DOOR
285203 285203 CENTERPOST BEARING KIT (INCLUDES ITEMS 13, 14 & 23)
3388851 3388851 CHANNEL ASSEMBLY (LEFT HAND SIDE)
3388850 3388850 CHANNEL ASSEMBLY (RIGHT HAND SIDE)
WP616099 WP616099 CLAMP
WP371502 WP371502 CLAMP
WP285655 WP285655 CLAMP
WP596669 WP596669 CLAMP
357030 357030 CLAMP, CAPACITOR
WP356138 WP356138 CLAMP, HOSE (2) (SUDS)
WP660658 WP660658 CLAMP, MOTOR
488946 488946 CLAMP, TUBING
7111P002-60 7111P002-60 CLAMP, WIRE 3/4
WP3355454 WP3355454 CLIP
W10854425 W10854425 CLIP
WP90016 WP90016 CLIP
WP3390902 WP3390902 CLIP
WP98234 WP98234 CLIP (2)
3390935 3390935 CLIP, DUCT LOCATOR
3389231 3389231 CLIP, FRONT PANEL (2)
8281256 8281256 CLIP, HARNESS
3391249 3391249 CLIP, HARNESS (2)
W10134185 W10134185 CLIP, HARNESS (2)
WP359364 WP359364 CLIP, LEVELING MECHANISM (2)
3350828 3350828 CLIP, RETAINER (2)
3349770 3349770 CLIP, SPRING TOP (2)
WP3388229 WP3388229 CLIP, TOE PANEL LOCK
285785 285785 CLUTCH
W11213338 W11213338 CONNECTOR
W10876590 W10876590 CONNECTOR
285442 285442 CONNECTOR KIT, PLASTIC DRAIN HOSE
3347243 3347243 CONNECTOR, 5 WAY (USES TERMINAL 352088)
661513 661513 CONTROL
341141 341141 CONTROL, ELECTRONIC
69632-1 69632-1 CONTROL, VARIBLE TEMPERATURE
285753A 285753A COUPLING
WP384496 WP384496 COUPLING, HOSE 10-16 X 1/2 (2)
WP16272 WP16272 COUPLR-HSE
3389683 3389683 COVE, TRANSITION PANEL (BLACK)
279780 279780 COVER
279814 279814 COVER
285202 285202 COVER, GEARCASE
WP3403607 WP3403607 CUTOFF-TML
80040 80040 DOG-AGIT
285751 285751 DOG-AGIT
W11663440 W11663440 DOOR
3387883 3387883 DOOR, FRONT (ALMOND)
3387876 3387876 DOOR, FRONT (GOLDEN HARVEST)
3387875 3387875 DOOR, FRONT (PLATINUM)
3387874 3387874 DOOR, FRONT (TOAST)
280083 280083 DOOR-REAR
72017 72017 DRAWER, STORAGE PAINT, TOUCH-UP (1/2OZ.) (WHITE)
WP661600 WP661600 DRIVE MOTOR
279811 279811 DRIVE MOTOR
WP3387911 WP3387911 DUCT-AIR
279700 279700 DUCT-LINT
279704 279704 DUCT-TRANS
WP3387223 WP3387223 ELECTRODE, SENSOR
285367 285367 ENAMAL, TOAST (1 QT. UNCUT)
W10891649 W10891649 END CAP (LEFT) (WHITE)
3389465 3389465 END CAP (LH) (ALMOND)
W10891648 W10891648 END CAP (RIGHT) (WHITE)
3389468 3389468 END CAP-LEFT HAND (GOLDEN WHEAT)
3389467 3389467 END CAP-LEFT HAND (PLATINUM)
3389466 3389466 END CAP-LEFT HAND (TOAST)
3389457 3389457 END CAP-RIGHT HAND (ALMOND)
3389460 3389460 END CAP-RIGHT HAND (GOLDEN WHEAT)
3389459 3389459 END CAP-RIGHT HAND (PLATINUM)
3389458 3389458 END CAP-RIGHT HAND (TOAST)
WPW10001130 WPW10001130 FOOT
WP358594 WP358594 FOOT, REAR (2)
W10814296 W10814296 GASKET, CENTER POST
285515 285515 GEARCASE
3360629 3360629 GEARCASE
261890 261890 GOLDEN HARVEST
261891 261891 GOLDEN HARVEST (UNCUT)
3391931 3391931 GRILLE, OUTLET
WP62691 WP62691 GROMMET, MOTOR (4)
LIT3390549 LIT3390549 GUIDE, LAUNDRY
LIT3390220 LIT3390220 GUIDE, USE AND CARE
3389523 3389523 HANDLE, DOOR (ALMOND)
3389526 3389526 HANDLE, DOOR (GOLDEN HARVEST)
3389525 3389525 HANDLE, DOOR (PLATINUM)
3389524 3389524 HANDLE, DOOR (TOAST)
3389522 3389522 HANDLE, DOOR (WHITE)
3391933 3391933 HARNESS - DRYER
3391920 3391920 HARNESS - WASHER
3350213 3350213 HARNESS, LID SWITCH
3389947 3389947 HARNESS, SENSOR
WP3387749 WP3387749 HEATER ELEMENT
WP61894 WP61894 HEATER, THERMOSTAT (NOTE: USED WITH 660039 THERMOSTAT ONLY)
W11175815 W11175815 HINGE & PIN ASSEMBLY (2)
3350102 3350102 HINGE, (LH)
3350101 3350101 HINGE, (RH)
285664 285664 HOSE
285871 285871 HOSE
63323 63323 HOSE, BLEACH
3350142 3350142 HOSE, DRAIN
W10834213 W10834213 HOSE, PRESSURE SWITCH
3352236 3352236 HOSE, WATER INLET (VACUUM BREAK TO MIXING VALVE)
WP89503 WP89503 HOSE-FILL
WP8544363 WP8544363 HOUSING
W11129408 W11129408 HOUSNG-OUT
LIT3389584 LIT3389584 INSTRUCTIONS, INSTALLATION (FOR MODEL LT7000XTW0)
3389589 3389589 INSTRUCTIONS, INSTALLATION (FOR MODEL LT7004XVW0)
285320 285320 IPHON BREAK KIT
279769 279769 KIT, THERMAL CUT-OFF (INCLUDES THERMOSTAT)
685463 685463 KIT, WIRE GROUNDING
W10801656 W10801656 KNOB
3392714 3392714 KNOB, CONTROL (3) (WHITE)
3391829 3391829 KNOB, PUSH-TO-START
696354 696354 KNOB, TIMER (DRYER)
LIT3350880 LIT3350880 LABEL, ENERGY GUIDE (FOR MODEL LT7000XTW0)
3352139 3352139 LABEL, ENERGY GUIDE (FOR MODEL LT7004XVW0)
LIT3387922 LIT3387922 LABEL, OPERATING INSTRUCTION
LIT3391934 LIT3391934 LABEL, WIRING DIAGRAM (FOR MODEL LT7000XTW0)
3392124 3392124 LABEL, WIRING DIAGRAM (FOR MODEL LT7004XTW0)
350941 350941 LEVELER (THINNER)
WPW10193874 WPW10193874 LID
3354573 3354573 LID (PLATINUM)
3354572 3354572 LID (TOAST)
WP3350152 WP3350152 LID, RETAINER
388451 388451 LID, TOP (ALMOND)
388454 388454 LID, TOP (GOLDEN WHEAT)
285790 285790 LINING
WP3349311 WP3349311 LINK
LIT3390384 LIT3390384 LIST, REPAIR PARTS
W11116924 W11116924 LOCATOR
62942 62942 LOCK, FILTER
WP345670 WP345670 LOCK, TOP
285208 285208 LUBRICANT (USE ONLY IN BRAKE SHOE ASSEMBLY ON ROLLER & PIN)
63493 63493 MOTOR, TIMER
W11676449 W11676449 MOVER-AGIT
388253A 388253A NEUTRAL ASSEMBLY
W10080180 W10080180 NUT
WP358160 WP358160 NUT
WP3389249 WP3389249 NUT
90984 90984 NUT, 5/16-18
WP3387709 WP3387709 NUT, HEX (2)
124829 124829 NUT, JAM (2)
WP688805 WP688805 NUT, KNURLED
WP21366 WP21366 NUT, LOCK
WP692400 WP692400 NUT, PUSH-IN
352292 352292 NUT, PUSH-IN (2)
350572 350572 OIL, GEARCASE (16 OZ.)
285219 285219 PAD
285744 285744 PAD
694398 694398 PAD, EXTRUDED
WP21097 WP21097 PAD, HINGE (2)
72112 72112 PAINT, (TOUCH-UP 1/2 OZ.) (TOAST)
799344 799344 PAINT, BULK (1 QT.) (WHITE (UNCUT))
285366 285366 PAINT, SPRAY (13 OZ.) (PLATINUM)
72110 72110 PAINT, TOUCH-UP 1/2 OZ. (GOLDEN HARVEST)
WP3349499 WP3349499 PANEL
WP3349455 WP3349455 PANEL
280039 280039 PANEL
279719 279719 PANEL
279718 279718 PANEL
3390081 3390081 PANEL, CONTROL
3349500 3349500 PANEL, FRONT (ALMOND)
3349503 3349503 PANEL, FRONT (GOLDEN HARVEST)
3392551 3392551 PANEL, FRONT (GOLDEN HARVEST)
3349502 3349502 PANEL, FRONT (PLATINUM)
3392550 3392550 PANEL, FRONT (PLATINUM)
3349501 3349501 PANEL, FRONT (TOAST)
3392549 3392549 PANEL, FRONT (TOAST)
8564987 8564987 PANEL, REAR (WASHER)
3349456 3349456 PANEL, SIDE (2) (SAME PANEL USED ON LEFT AND RIGHT SIDE) (ALMOND)
3349459 3349459 PANEL, SIDE (2) (SAME PANEL USED ON LEFT AND RIGHT SIDE) (NEW GOLD)
3349458 3349458 PANEL, SIDE (2) (SAME PANEL USED ON LEFT AND RIGHT SIDE) (PLATINUM)
3349457 3349457 PANEL, SIDE (2) (SAME PANEL USED ON LEFT AND RIGHT SIDE) (TOAST)
3389265 3389265 PANEL, SIDE (L.H.) (ALMOND)
3389257 3389257 PANEL, SIDE (L.H.) (ALMOND)
3389268 3389268 PANEL, SIDE (L.H.) (GOLDEN HARVEST)
3389260 3389260 PANEL, SIDE (L.H.) (GOLDEN WHEAT)
3389267 3389267 PANEL, SIDE (L.H.) (PLATINUM PANEL, SIDE (R.H.))
3389259 3389259 PANEL, SIDE (L.H.) (PLATINUM)
3389258 3389258 PANEL, SIDE (L.H.) (TOAST)
3389266 3389266 PANEL, SIDE (L.H.) (TOAST)
3389264 3389264 PANEL, SIDE (L.H.) (WHITE)
3389256 3389256 PANEL, SIDE (L.H.) (WHITE)
3388959 3388959 PANEL, TOE (ALMOND)
3388962 3388962 PANEL, TOE (GOLDEN WHEAT)
3388961 3388961 PANEL, TOE (PLATINUM)
3388960 3388960 PANEL, TOE (TOAST)
3388958 3388958 PANEL, TOE (WHITE)
3389273 3389273 PANEL, TRANSITION (ALMOND)
3389276 3389276 PANEL, TRANSITION (GOLDEN HARVEST)
3389275 3389275 PANEL, TRANSITION (PLATINUM)
3389274 3389274 PANEL, TRANSITION (TOAST)
3389272 3389272 PANEL, TRANSITION (WHITE)
285609 285609 PARTS-MISC
WP62611 WP62611 PLATE, MOTOR MOUNT TO GEARCASE
285368 285368 PLATINUM (UNCUT)
285868 285868 PLUG
3350130 3350130 PLUG, 3 WAY (USES TERMINAL 94614)
3350212 3350212 PLUG, 3-WAY (USES TERMINAL 94613)
WP660975 WP660975 PLUG, TOP TO CABINET 689587 (ALT.) 694010 (ALT.)
350938 350938 PRIMER, GRAY
63523 63523 PROTECTOR, HARNESS
279640 279640 PULLEY-IDR
3349697 3349697 RAIL, BACK TOP
WP3390291 WP3390291 RANGE THERMOSTAT
WP694674 WP694674 RANGE THERMOSTAT
3350211 3350211 RECEPTACLE, 3 WAY (USES TERMINAL 94614)
WP62889 WP62889 RECEPTACLE, TERMINAL (3-WAY) (CONNECTS WITH HARNESS)
3349749 3349749 RESTRAINER, BASE
WP3350222 WP3350222 RETAINER
WP8546127 WP8546127 RETAINER
3350506 3350506 RETAINER, HOSE
WPW10086010 WPW10086010 RETAINER, MOTOR (2)
62677 62677 RETAINER, SPRING
WPW10145155 WPW10145155 RETAINER, SUSPENSION SPRING (ALMOND)
WP62658 WP62658 RING
285353 285353 RING
W10083190 W10083190 RING, RETAINING
90369 90369 RING, RETAINING (2)
WP63134 WP63134 RING, SOUND DEADENING
WPW10080230 WPW10080230 RING, SPIN TUBE SUPPORT
WPW10072840 WPW10072840 RING-O
285765 285765 RING-RETNR
W10880720 W10880720 RING-TUB
W11033823 W11033823 RING-WIRE
WP3389644 WP3389644 SCREEN, LINT
WP3351614 WP3351614 SCREW
WP273556 WP273556 SCREW
W11573574 W11573574 SCREW
WP3400516 WP3400516 SCREW
WPW10119828 WPW10119828 SCREW
WP488729 WP488729 SCREW
WP90767 WP90767 SCREW
718091 718091 SCREW
WP3389420 WP3389420 SCREW
WP308685 WP308685 SCREW
W10850756 W10850756 SCREW
WP488627 WP488627 SCREW
WPW10139210 WPW10139210 SCREW
WP3395530 WP3395530 SCREW
WP681414 WP681414 SCREW
WP356418 WP356418 SCREW
WP3387230 WP3387230 SCREW
WP358237 WP358237 SCREW & WASHER (5/16 - 24 X 1)
354764 354764 SCREW AND WASHER
WP693304 WP693304 SCREW AND WASHER
WP3400036 WP3400036 SCREW, 10-24 X 1
690372 690372 SCREW, 11-16 X 7/8
62735 62735 SCREW, 5/16-24 X 3/16 (3) (GEARCASE TO TUB SUPPORT)
309051 309051 SCREW, 8A X 3/8 (2)
Y015627 Y015627 SCREW, HEX HD CAP 5/16 X 5/8
3349332 3349332 SCREW, SHOULDER (2)
WP3390631 WP3390631 SCREW,10-16 X 5/16
W11095997 W11095997 SEAL
WP8566209 WP8566209 SEAL
280114 280114 SEAL
WP697770 WP697770 SEAL
WP3391906 WP3391906 SEAL
WP64002 WP64002 SEAL, AGITATOR
WP8577376 WP8577376 SEAL, CENTERPOST
WP356427 WP356427 SEAL, DRIVE TUBE
WP91939 WP91939 SEAL, OIL
WP697813 WP697813 SEAL, OUTLET HOUSING
285352 285352 SEAL, THRUST PLUG
WP3349985 WP3349985 SEAL-COVER
WP3390735 WP3390735 SEAL-DOOR
WP3976308 WP3976308 SEAL-TUB
WP285195 WP285195 SEALER, GASKET (.20 FL. OZ.) (6 ML)
WPW10359272 WPW10359272 SHAFT
WPW10359271 WPW10359271 SHAFT
WP389387 WP389387 SHAFT, AGITATOR (COMPLETE)
WP389231 WP389231 SHAFT-AGIT
WP3946532 WP3946532 SHIELD
3390722 3390722 SHIELD, CONSOLE TO DRUM
3390611 3390611 SHIELD, CORNER (LEFT REAR)
3390608 3390608 SHIELD, CORNER RIGHT REAR
W11108181 W11108181 SHIELD, FRONT
3390609 3390609 SHIELD, HARNESS
3350145 3350145 SHIELD, LID SWITCH
WP359231 WP359231 SHIELD, LID SWITCH
3390336 3390336 SHIELD, THERMOSTAT
W10838408 W10838408 SHIELD-MTR
285438 285438 SHOE-BRAKE
279823 279823 SIDE EXHAUST KIT
WP3946509 WP3946509 SKATE PLT
3388183 3388183 SKIRT, TIMER KNOB (WASHER)
WP63022 WP63022 SLEEVE
285658 285658 SLEEVE
285321 285321 SLEEVE KIT, PLASTIC DRAIN HOSE (CONTAINS 2 SLEEVES)
3389682 3389682 SPACER (2)
356937 356937 SPACER, DRIVE TUBE
3390688 3390688 SPACER- FOAM PAD (2)
350930 350930 SPRAY (13 OZ.) (WHITE)
WP63748 WP63748 SPRING
WPW10446781 WPW10446781 SPRING, IDLER
3350135 3350135 SPRING, LEVER BRACKET
WP63907 WP63907 SPRING, SUSPENSION (3)
62676 62676 SPRING, WASHER AGITATOR
WPW10250667 WPW10250667 SPRING,COUNTERWEIGHT
687000 687000 STRAIN-RELIEF (POWER CORD)
22965 22965 STRAP, GROUNDING
WP358684 WP358684 STRIKE, LID
280184 280184 SUPPORT
WPW10314173 WPW10314173 SUPPORT
279827 279827 SWITCH, MOTOR START (USE W/3391886 MOTOR)
3348819 3348819 SWITCH, PRESSURE
279173 279173 SWITCH, PUSH-TO-START
W10820036 W10820036 SWITCH-LID
WP3391902 WP3391902 SWITCH-LID
WP8529896 WP8529896 SWITCH-MTR
3954758 3954758 SWTCH-TEMP
279393 279393 TERMINAL BLOCK SCREW KIT (FOR TERMINAL BLOCK)
279318 279318 TERMINAL, TINNED & BRASS (3) (INCLUDES ILLUS. 42)
WPW10339879 WPW10339879 TIE-WIRE
3391377 3391377 TIMER, DRYER
WP3351744 WP3351744 TIMER, WASHER
285365 285365 TOAST
3349818 3349818 TOP, CONSOLE (ALMOND)
3349821 3349821 TOP, CONSOLE (GOLDEN WHEAT)
3349820 3349820 TOP, CONSOLE (PLATINUM)
3349819 3349819 TOP, CONSOLE (TOAST)
3349817 3349817 TOP, CONSOLE (WHITE)
3389537 3389537 TOP, DRYER
WPW10512946 WPW10512946 TRI-RING (4)
3361595 3361595 TUB-OUTER
WP64208 WP64208 TUBE-SPIN
3349343 3349343 TV STAND ASSEMBLY (INCLUDES ILLUS. 6, 7, 18 & 26)
285805 285805 VALVE
WP388815 WP388815 WASHER
285620 285620 WASHER
WPW10121334 WPW10121334 WASHER
3349340 3349340 WASHER (2)
285766 285766 WASHER KIT, THRUST
62618 62618 WASHER, CAM THRUST
WP16123 WP16123 WASHER, INLET HOSE (1-1/16 X 5/8)(4)
WP63292 WP63292 WASHER, SPIN TUBE THRUST
W11236646 W11236646 WASHER, SUPPORT
62619 62619 WASHER, WASHER AGITATOR GEAR
WP3363394 WP3363394 WATER PUMP
WP697772 WP697772 WHEEL, BLOWER
685449 685449 WIRE
3387377 3387377 WIRE, BELT SWITCH
690236 690236 WIRE, GROUND
72113 72113 WIRE, SPLICING 25 FT. BLACK 12 GA. 150~C (PLATINUM)
Main Menu x
