Model Image
Manufacturer

Whirlpool

Model Number

MFI2067AEB

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
13042305 13042305 ADAPTER (LT)
13042306 13042306 ADAPTER (RT)
W10184223 W10184223 ADAPTER, BIN (CENTER)
12575101WD 12575101WD BACK, MACH COMP
67003794 67003794 BAR- TEMP
12457108 12457108 BASEPAN
W10184227 W10184227 BIN, UPPER
67006981 67006981 BIN- LWR F
WPW10324088 WPW10324088 BIN-ICE
W10156818 W10156818 BLADE, FAN
WP67006337 WP67006337 BLADE- FAN
WP67003405 WP67003405 BLOCK- PIV
67006294 67006294 BOARD, L.V.
WP67006390 WP67006390 BOX- HV CO
WP12227304WD WP12227304WD BRACE- CRI
WPW10330993 WPW10330993 BRACKET
WPW10330991 WPW10330991 BRACKET
WP67004953 WP67004953 BRACKET
W10187469 W10187469 BRACKET
12456801V 12456801V BRACKET, FOOT
12906303WD 12906303WD BRACKET, FOOT CABINET
67006325 67006325 BRACKET- F
67007111 67007111 BRACKET- S
67006324 67006324 BRACKET- W
W10235358 W10235358 BRACKET/GLIDE (ASSEMBLY)
WP67006310 WP67006310 BUCKET, REF. DR GAL
WP67006313 WP67006313 BUCKET- CH
67006229A 67006229A BUTTERTRAY
W11395888 W11395888 CAP-FILTER
W11266639 W11266639 CHILLER
WPW10131128 WPW10131128 CHUTE- EXT
W10833902 W10833902 CLAMP
WPM0104106 WPM0104106 CLIP
10547002 10547002 CLIP, DRIER
10623002 10623002 CLIP, EVAPORATOR
M0104102 M0104102 CLIP- CORD
67001067 67001067 CLIP- DRAI
W11673433 W11673433 CLIP- EVAP
W11712696 W11712696 CLIP- FAN
WP12627302 WP12627302 CLIP- TOE
WP67003639 WP67003639 CLOSER
W10160407 W10160407 COMPRESSOR KIT (CONTAINS ITEMS 12, 17, 27, & 29)
WP67006131 WP67006131 CONDENSER
WPW10127427 WPW10127427 CONTROL
W11221359 W11221359 CONTROL BOARD
W10890094 W10890094 CONTROL BOARD
W10740217 W10740217 CONTROL BOARD
67007121 67007121 CORD, POWER
WP67005956 WP67005956 COVER
W10827015 W10827015 COVER
67006428 67006428 COVER
67006318 67006318 COVER
12987301 12987301 COVER
67006427 67006427 COVER CON
13033601 13033601 COVER, ICE BOX HARNESS
12921801 12921801 COVER, LIGHT
12701908 12701908 COVER, WATER VALVE
67003485 67003485 COVER- COR
12981401B 12981401B COVER- FIL
WP67003924 WP67003924 COVER- FZ
67006350 67006350 COVER- ICE
W10337647 W10337647 COVER- TOP
67006329 67006329 COVER- WAT
12960101 12960101 COVER- WAT
12935801 12935801 COVER-EVAP
WP67006331 WP67006331 COVER-FILT
67006384 67006384 DAM LEFT
67006385 67006385 DAM RIGHT
WP67006311 WP67006311 DISPENSER-
67007109 67007109 DIVIDER I
67006373 67006373 DIVIDER, UPR BIN
WP67002321 WP67002321 DIVIDER- P
W11592374 W11592374 DOOR HINGE
W11592375 W11592375 DOOR HINGE
WP67006312 WP67006312 DOOR- CHIL
WP67003637 WP67003637 DOOR-COMP
67006971 67006971 DOR-FIP BL
12978012BQ 12978012BQ DOR-FIP BL
12978011BQ 12978011BQ DOR-FIP BL
WPW10151713 WPW10151713 DRAWER SLIDE RAIL
WPB2150504 WPB2150504 DRIER
WP12656018 WP12656018 ENDCAP
WP12656105 WP12656105 ENDCAP
12002730 12002730 EVAPORATOR
WP67006010 WP67006010 EXTR- GLAS
WP67006288 WP67006288 FACADE (BLK)
W11177593 W11177593 FEET-LVLNG
67003796 67003796 FIBER- ACO
12691605 12691605 FOIL LIGH
WP67006185 WP67006185 FRAME
WP67005923 WP67005923 FRONT- CRI
W10815413 W10815413 FUNNEL
WP67006341 WP67006341 GASKET
W11451451 W11451451 GASKET
67006429 67006429 GASKET
W11378944 W11378944 GASKET ASSEMBLY
WPW10436253 WPW10436253 GASKET ASSEMBLY
B5759649 B5759649 GASKET MC
WPB8381501 WPB8381501 GASKET- DR
67002329 67002329 GASKET- PA
12002497 12002497 GEAR (INCLDS. BOTH)
WP67006655 WP67006655 GLASS SHELF
WP67002332 WP67002332 GLASS- PAN
WPW10235370 WPW10235370 GLIDE
WPW10235368 WPW10235368 GLIDE
WP12999301B WP12999301B GRILLE
W11176847 W11176847 GRILLE- FR
W10555984 W10555984 GRILLE- RE
WPW10534153 WPW10534153 GRILLE-FRT
12996601 12996601 GROMMET
WP61004743 WP61004743 GROMMET- B
67003493 67003493 GROMMET- C
67005680 67005680 GROMMET- C
W11676465 W11676465 GROMMET- F
WP13004701B WP13004701B HANDLE
67007105 67007105 HANDLE
67007114 67007114 HARNESS I
67007120 67007120 HARNESS M
13032901 13032901 HARNS-WIRE
67006386 67006386 HEATER- DE
W10918164 W10918164 HINGE- CEN
67006442 67006442 HINGE-DOOR
12656202 12656202 HOUSING
W11702858 W11702858 HOUSING- L
12806601 12806601 HOUSING- L
W10583817 W10583817 ICEMAKER
WP63052-2 WP63052-2 IMPELLER
67006334 67006334 IMPINGER A
12820504 12820504 INSULATION
W11498983 W11498983 KNOB
67007115 67007115 LADDER SI
67006354 67006354 LADDER SI
67006358 67006358 LADDER, CENTER
W11679940 W11679940 LIGHT BULB
67006328 67006328 MODULE, REF. LIGHT
WP67006423 WP67006423 MODULE- FR
67006342 67006342 MOTOR- AUG
WP67006968 WP67006968 MOTOR- FAN
W11613295 W11613295 MOTOR-COND
2324038 2324038 NAMEPLATE
M0286708 M0286708 NUT- SPEED
12828140 12828140 OWNERS MAN
WPW10131124 WPW10131124 PADDLE- DI
WP67002659 WP67002659 PAN- CRISP
WP12579803 WP12579803 PAN- DRAIN
W11490183 W11490183 PAN-UTILTY
WP67006113 WP67006113 PLATE
WP12956202 WP12956202 RESERVOIR
W10826790 W10826790 RETAINER-
W10826791 W10826791 RETAINER-
67006295 67006295 RING- TARG
WPM1205302 WPM1205302 RIVET
WP10450603 WP10450603 ROLLER
WP12580304 WP12580304 ROLLER BRACKET ASSEMBLY
W10709795 W10709795 SCREW
W11233072 W11233072 SCREW
WP67006415 WP67006415 SCREW
WP8281196 WP8281196 SCREW
WP489349 WP489349 SCREW
WP3387230 WP3387230 SCREW
WP67006380 WP67006380 SCREW
WP98165 WP98165 SCREW
WP67004954 WP67004954 SCREW
71003131 71003131 SCREW
WP33001882 WP33001882 SCREW
67006425 67006425 SCREW
12992301 12992301 SCREW
67006697 67006697 SCREW
12846902 12846902 SCREW
WP489474 WP489474 SCREW
67006491 67006491 SCREW
WP3400805 WP3400805 SCREW
67007110 67007110 SCREW
12991101 12991101 SCREW, HANDLE (BLACK)
WPW10287601 WPW10287601 SEAL
WPM0500703 WPM0500703 SEAL- O RI
WP854334 WP854334 SEAL-STRIP
W11028221 W11028221 SHAFT
67006969 67006969 SHELF GLI
67006977 67006977 SHELF STA
12999501 12999501 SHIM, TOP HINGE (LEFT HAND)
12999502 12999502 SHIM, TOP HINGE (RIGHT HAND)
67006335 67006335 SHROUD IC
67001090 67001090 SHROUD, CONDENSER FAN
W11700329 W11700329 SHROUD- EV
WP67005864 WP67005864 SLIDE
WP13031602 WP13031602 SLIDE- DRA
WP67003793 WP67003793 SLIDE- TEM
W11447232 W11447232 SOCKET
67006344 67006344 SOLENOID
WP12565502 WP12565502 SPRING- CH
67006348 67006348 SPRING- SO
W10613606 W10613606 START-DEV
W11708403 W11708403 STOP-DOOR
WP12576801 WP12576801 STRAP, BALE
WP12227305WD WP12227305WD SUPPORT
16026312 16026312 SVC MAN, BTM MT
W11396033 W11396033 SWITCH
W11445850 W11445850 SWITCH
67007122 67007122 TAG ENERG
16026830 16026830 TECH SHT, BTM MT
12002355 12002355 THERMISTOR
WP67006387 WP67006387 THERMOSTAT
WP67001719 WP67001719 TRACK
67215-2 67215-2 TRAY EGG
WP67001279 WP67001279 TRAY- DAIR
W11547653 W11547653 TRAY-DRIP
WPW10231485 WPW10231485 TRIM-SHELF
67001656 67001656 TRIVET- BO
WP12866903 WP12866903 TUBE
67001066 67001066 TUBE- DRAI
W11415785 W11415785 TUBE-WATER
67006322 67006322 VALVE- DUA
67006346 67006346 WASHER
EDR4RXD1 EDR4RXD1 WATER FILTER
12962106 12962106 WATERLINE, DOOR
67006970 67006970 WATERLINE-
15003955 15003955 WIRING INFORMATION
67006347 67006347 YOKE- SOLE
