Model Image
Manufacturer

Whirlpool

Model Number

MGR8670WB0

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
WP5789A598-60 WP5789A598-60 Whirlpool ACCESSORY PARTS, KIT, LP CONVERSION
3601P336-45 3601P336-45 Whirlpool BAFFL-BRNR
3601P356-45 3601P356-45 Whirlpool BAFFL-BRNR
3601F380-51 3601F380-51 Whirlpool BAFFLE INS
WPW10211368 WPW10211368 Whirlpool BOTTM-OVEN
4005F753-45 4005F753-45 Whirlpool BOTTM-OVEN
3401F082-45 3401F082-45 Whirlpool BOX-BURNER
WP3801F656-51 WP3801F656-51 Whirlpool BRACKET
3801F886-51 3801F886-51 Whirlpool BRKT-MNTG
W10173314 W10173314 Whirlpool BRKT-MNTG
3801P918-51 3801P918-51 Whirlpool BRKT-SUPRT
3801P822-45 3801P822-45 Whirlpool BRKT-SUPRT
3801P798-51 3801P798-51 Whirlpool BRKT-SUPRT
7505P331-60 7505P331-60 Whirlpool BURNER, BAKE
W10160904 W10160904 Whirlpool BURNR-BRLR
WPW10406283 WPW10406283 Whirlpool BURNR-HEAD
WPW10406797 WPW10406797 Whirlpool BURNR-HEAD
WPW10406878 WPW10406878 Whirlpool BURNR-HEAD
WPW10406243 WPW10406243 Whirlpool BURNR-HEAD
WPW10183369 WPW10183369 Whirlpool CAP-BURNER
WPW10183368 WPW10183368 Whirlpool CAP-BURNER
WPW10183370 WPW10183370 Whirlpool CAP-BURNER
WPW10169974 WPW10169974 Whirlpool CAP-BURNER
WPW10173832 WPW10173832 Whirlpool CAP-BURNER
WPW10169975 WPW10169975 Whirlpool CAP-BURNER
WPW10183371 WPW10183371 Whirlpool CAP-BURNER
W10169973 W10169973 Whirlpool CAP-BURNER
WP8273564 WP8273564 Whirlpool CLIP
8019P013-60 8019P013-60 Whirlpool CLIP
74008835 74008835 Whirlpool CLIP, RETAINER
W10271869 W10271869 Whirlpool CNVRSN-KIT
WPW10271775 WPW10271775 Whirlpool CONTROL BOARD
WPW10271776 WPW10271776 Whirlpool CONTROL BOARD
WPW10271777 WPW10271777 Whirlpool CONTROL BOARD
W10289580 W10289580 Whirlpool COOKTOP
W10289581 W10289581 Whirlpool COOKTOP
W10289564 W10289564 Whirlpool COOKTOP
WP7402P109-60 WP7402P109-60 Whirlpool CORD, POWER
4005F421-45 4005F421-45 Whirlpool COVER IGN
4005P711-51 4005P711-51 Whirlpool COVER-REAR
4005P704-51 4005P704-51 Whirlpool COVER-REAR
W10243047 W10243047 Whirlpool COVER-REAR
W10243038 W10243038 Whirlpool COVER-REAR
W10205618 W10205618 Whirlpool COVER-REAR
W10792991 W10792991 Whirlpool DOOR DOOR LATCH
WPW10171748 WPW10171748 Whirlpool DOOR HANDLE
WPW10171747 WPW10171747 Whirlpool DOOR HANDLE
WPW10161708 WPW10161708 Whirlpool DOOR HANDLE
8038P037-60 8038P037-60 Whirlpool DRAWER, STOP
WP3405F037-80 WP3405F037-80 Whirlpool DRAWR-UTIL
W10163969 W10163969 Whirlpool ENDCAP-PNL
W10171416 W10171416 Whirlpool ENDCAP-PNL
W10163970 W10163970 Whirlpool ENDCAP-PNL
W10163968 W10163968 Whirlpool ENDCAP-PNL
W10171417 W10171417 Whirlpool ENDCAP-PNL
W10163967 W10163967 Whirlpool ENDCAP-PNL
241430 241430 Whirlpool FOIL-ALUM
W11665456 W11665456 Whirlpool FOOT-LEVEL
N_P N_P Whirlpool FRAME, FRONT (NOT SERVICED)
W10306689 W10306689 Whirlpool GASKET, DOOR
W11562931 W11562931 Whirlpool GASKT-DOOR
WPW10181725 WPW10181725 Whirlpool GLASS DOOR
74003645 74003645 Whirlpool GLASS, INNER
WPW10249311 WPW10249311 Whirlpool GRATE, SET (BLACK)
WPW10249312 WPW10249312 Whirlpool GRATE, SET (WETSTONE)
W10239463 W10239463 Whirlpool GUIDE, USE AND CARE
WP74010753 WP74010753 Whirlpool HARNESS- S
W10237604 W10237604 Whirlpool HARNS-WIRE
WP3604F382-81 WP3604F382-81 Whirlpool HEAT SHIELD, VISOR (WHITE)
WP3604F382-88 WP3604F382-88 Whirlpool HEAT SHIELD,VISOR (BISCUIT)
74010546 74010546 Whirlpool HINGE, DOOR
W10171749 W10171749 Whirlpool HNDLE-DOOR
W10169901 W10169901 Whirlpool HOLDER-ORF
W10169902 W10169902 Whirlpool HOLDER-ORF
W10169903 W10169903 Whirlpool HOLDER-ORF
W10169906 W10169906 Whirlpool HOLDER-ORF
W10169907 W10169907 Whirlpool HOLDER-ORF
74007498 74007498 Whirlpool IGNITER, OVEN
WP7432P136-60 WP7432P136-60 Whirlpool IGNTR-OVEN
WPW10216419 WPW10216419 Whirlpool IGNTR-SURF
W10258096 W10258096 Whirlpool INSTALLATION INSTRUCTIONS
W11161816 W11161816 Whirlpool INSULATION
7002P246-60 7002P246-60 Whirlpool INSULATION
7002P482-60 7002P482-60 Whirlpool INSULATION
WPW10208653 WPW10208653 Whirlpool INSULATION
W10243056 W10243056 Whirlpool INSULATION
W10182346 W10182346 Whirlpool INSULATION
12002421 12002421 Whirlpool KIT, SUPPLY TUBE AND SCREW
WPW10200192 WPW10200192 Whirlpool KNOB
WPW10200193 WPW10200193 Whirlpool KNOB
WPW10111302 WPW10111302 Whirlpool KNOB
W11194991 W11194991 Whirlpool KNOB
8009 8009 Whirlpool LIGHT BULB
W10172591 W10172591 Whirlpool LINER-DOOR
W10172590 W10172590 Whirlpool LINERDOOR
WP2402W297-19 WP2402W297-19 Whirlpool LINING, DOOR
74009098 74009098 Whirlpool MODULE, SPARK
WP488130 WP488130 Whirlpool NUT
WP3400029 WP3400029 Whirlpool NUT
7103P030-60 7103P030-60 Whirlpool NUT- WING
74008834 74008834 Whirlpool ORIFICE
W10853607 W10853607 Whirlpool ORIFICE
W10178934 W10178934 Whirlpool ORIFICE
511873 511873 Whirlpool PAINT
4392900 4392900 Whirlpool PAINT
799344 799344 Whirlpool PAINT
350942 350942 Whirlpool PAINT, PRESSURIZED SPRAY (12 OZ.) (PRIMER, WHITE)
WPW10225564 WPW10225564 Whirlpool PANEL, CONTROL (STAINLESS)
WPW10214541 WPW10214541 Whirlpool PANEL, OUTER DOOR (BLACK)
WPW10097300 WPW10097300 Whirlpool PANEL, OUTER DOOR (STAINLESS)
WP2618F172-57 WP2618F172-57 Whirlpool PANEL, SIDE (BISCUIT)
WP2618F172-69 WP2618F172-69 Whirlpool PANEL, SIDE (BLACK)
WP2618F172-58 WP2618F172-58 Whirlpool PANEL, SIDE (WHITE)
W10172596 W10172596 Whirlpool PANEL-DRWR
W10172599 W10172599 Whirlpool PANEL-DRWR
W10172598 W10172598 Whirlpool PANEL-DRWR
W10172597 W10172597 Whirlpool PANEL-DRWR
W10225561 W10225561 Whirlpool PANL-CNTRL
W10225562 W10225562 Whirlpool PANL-CNTRL
W10225563 W10225563 Whirlpool PANL-CNTRL
W10211381 W10211381 Whirlpool PANL-MNFLD
W10211395 W10211395 Whirlpool PANL-MNFLD
W10211382 W10211382 Whirlpool PANL-MNFLD
W10211380 W10211380 Whirlpool PANL-MNFLD
7513P499-60 7513P499-60 Whirlpool PIPE-MNFLD
3605F146-51 3605F146-51 Whirlpool PLATE
WPW10256908 WPW10256908 Whirlpool RACK-OVEN
WP3406P034-51 WP3406P034-51 Whirlpool RAIL, DRAWER
WP74010551 WP74010551 Whirlpool RECEIVER-
8212471 8212471 Whirlpool REFINISHING MATERIAL (TOUCH-UP SELF-CLEAN(1/2 PT))
12002604 12002604 Whirlpool REGULATOR
3804F316-51 3804F316-51 Whirlpool RETAINER
WPW10272883 WPW10272883 Whirlpool ROLLER
WP7101P072-60 WP7101P072-60 Whirlpool SCREW
WPY706189 WPY706189 Whirlpool SCREW
WP3196557 WP3196557 Whirlpool SCREW
WP8273062 WP8273062 Whirlpool SCREW
WP74009857 WP74009857 Whirlpool SCREW
WP74003976 WP74003976 Whirlpool SCREW
74005401 74005401 Whirlpool SCREW
W10491985 W10491985 Whirlpool SCREW
WP4159193 WP4159193 Whirlpool SCREW
W11233072 W11233072 Whirlpool SCREW
W11169708 W11169708 Whirlpool SCREW
W11684507 W11684507 Whirlpool SCREW
74008798 74008798 Whirlpool SCREW W/SHOULDER (NO.8)
WP3368921 WP3368921 Whirlpool SCREW-TORX
WPW10131827 WPW10131827 Whirlpool SENSOR
WP74005231 WP74005231 Whirlpool SHAFT, ROLLER
WP3604F381-19 WP3604F381-19 Whirlpool SHIELD, VENT EXT
3604F382-09 3604F382-09 Whirlpool SHIELD-HT
W11594027 W11594027 Whirlpool SOCKT-LITE
W11190816 W11190816 Whirlpool SPACER
74008690 74008690 Whirlpool SPACER, SIDE PANEL
74008761 74008761 Whirlpool SPACER, SNAP-IN
4392901 4392901 Whirlpool SPRAY
285006 285006 Whirlpool SPRAY
350930 350930 Whirlpool SPRAY
WPW10170508 WPW10170508 Whirlpool SPUD-ORFCE
WPW10170506 WPW10170506 Whirlpool SPUD-ORFCE
W10251991 W10251991 Whirlpool SPUD-ORFCE
4820F015-59 4820F015-59 Whirlpool STRAP
3807P680-45 3807P680-45 Whirlpool SUPPORT
WP74004224 WP74004224 Whirlpool TAPE
W10239472 W10239472 Whirlpool TECH SHEET
9762761 9762761 Whirlpool TIPS, SAFE COOKING (ENGLISH)
74008830 74008830 Whirlpool TUBING, BROIL
W10247148 W10247148 Whirlpool TUBING-GAS
72032 72032 Whirlpool TUCHUP
72017 72017 Whirlpool TUCHUP
4392899 4392899 Whirlpool TUCHUP
WP7502P500-60 WP7502P500-60 Whirlpool VALVE (12K) (LEFT FRONT & RIGHT REAR)
74010751 74010751 Whirlpool VALVE (RF)
WP7502P499-60 WP7502P499-60 Whirlpool VALVE-BRNR
W10269504 W10269504 Whirlpool VALVE-BRNR
8026P080-60 8026P080-60 Whirlpool VENT, OVEN
