Model Image
Manufacturer

Whirlpool

Model Number

MGRH865QDQ13

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
3601P356-45 3601P356-45 BAFFL-BRNR
3601P336-45 3601P336-45 BAFFL-BRNR
3601F380-51 3601F380-51 BAFFLE INS
WPW10211368 WPW10211368 BOTTM-OVEN
WP3801F656-51 WP3801F656-51 BRACKET
WP3801F844-51 WP3801F844-51 BRACKET, CONTROL
3801P858-45 3801P858-45 BRACKET, HANDLE (LEFT)
74009413 74009413 BRACKET, HANDLE (RIGHT)
3801F886-51 3801F886-51 BRKT-MNTG
WP3605F337-51 WP3605F337-51 BRKT-MNTG
3801P822-45 3801P822-45 BRKT-SUPRT
3801P798-51 3801P798-51 BRKT-SUPRT
31945701 31945701 BURNER BACK
74008820 74008820 BURNER BR
WPW10406243 WPW10406243 BURNR-HEAD
WPW10406878 WPW10406878 BURNR-HEAD
WPW10406283 WPW10406283 BURNR-HEAD
WP74007422 WP74007422 CAP, BURNER (LR) (GRAY)
WPW10154101 WPW10154101 CAP-BURNER
WP74007418 WP74007418 CAP-BURNER
WP74007419 WP74007419 CAP-BURNER
WP74007417 WP74007417 CAP-BURNER
WP3191898 WP3191898 CAP-BURNER
WP74007415 WP74007415 CAP-BURNER
WP74007420 WP74007420 CAP-BURNER
WP74007421 WP74007421 CAP-BURNER
8019P026-60 8019P026-60 CLIP
8019P013-60 8019P013-60 CLIP, NYLON
74008835 74008835 CLIP- RETA
WP5702M030-60 WP5702M030-60 CONTROL (INCLUDES OVERLAY) (BISQUE)
WP5702M028-60 WP5702M028-60 CONTROL (INCLUDES OVERLAY) (BLACK)
WP5702M029-60 WP5702M029-60 CONTROL (INCLUDES OVERLAY) (WHITE)
W10318931 W10318931 COOKTOP
74009116 74009116 COOKTOP
74009115 74009115 COOKTOP (WHITE)
74008876 74008876 CORD, POWER
4005F803-51 4005F803-51 COVER
74009653 74009653 COVER BRO
4005F421-45 4005F421-45 COVER IGN
74009652 74009652 COVER MAI
31955101 31955101 COVER, LOWER WIRE
4005P711-51 4005P711-51 COVER-REAR
4002F347-51 4002F347-51 COVERREAR
W10792991 W10792991 DOOR DOOR LATCH
WP3608F126-71 WP3608F126-71 DOOR TRIM
74008688 74008688 DRAWER, STOP
WP3405F037-80 WP3405F037-80 DRAWR-UTIL
74009080 74009080 END CAP L
74009079 74009079 ENDCAP, LEFT HAND (WHITE)
74009022 74009022 ENDCAP, RIGHT HAND (BLACK)
74009077 74009077 ENDCAP, RIGHT HAND (WHITE)
74009023 74009023 ENDCAP-PNL
3807F702-78 3807F702-78 ENDCAP-PNL
WP74011174 WP74011174 FAN, CONVECTION
74008818 74008818 FITTING, BROILER
241430 241430 FOIL-ALUM
100000 100000 FOLLOWING PARTS NOT ILLUSTRATED
W11665456 W11665456 FOOT-LEVEL
W11562931 W11562931 GASKT-DOOR
74008682 74008682 GLASS, OUTER DOOR (BISQUE)
WPW10160908 WPW10160908 GLASS, OUTER DOOR (BLACK)
74003645 74003645 GLASS-DOOR
74008681 74008681 GLASS-DOOR
WP74009122 WP74009122 GRATE, BURNER (2) (TAUPE)
74009120 74009120 GRATE- DOU
74009121 74009121 GRATE- DOU
261582 261582 GREASE
WP7701P523-60 WP7701P523-60 HANDLE, DOOR (BISQUE)
WP74011675 WP74011675 HANDLE- DO
74011777 74011777 HANDLE- DO
W10129628 W10129628 HARNESS B
WP74010630 WP74010630 HARNESS- S
74010546 74010546 HINGE, DOOR
WP74009099 WP74009099 HOLDER-ORF
W10154209 W10154209 HOLDER-ORF
W10159266 W10159266 HOLDER-ORF
WP7432P136-60 WP7432P136-60 IGNTR-OVEN
74007498 74007498 IGNTR-OVEN
WP74009958 WP74009958 IGNTR-SURF
W10156248 W10156248 INSTALLATION INSTRUCTIONS
7002P484-60 7002P484-60 INSULATION
7002P494-60 7002P494-60 INSULATION
7002P492-60 7002P492-60 INSULATION
WPW10208653 WPW10208653 INSULATION
74009093 74009093 INSULATION
W11161816 W11161816 INSULATION
7002P246-60 7002P246-60 INSULATION
799832 799832 KIT, PORCELAIN REPAIR (WHITE)
12002421 12002421 KIT, SUPPLY TUBE AND SCREW
WP74009773 WP74009773 KNOB BLK
74009774 74009774 KNOB BSQ
WP74009775 WP74009775 KNOB WHT
8009 8009 LIGHT BULB
WP74011278 WP74011278 LIGHT- OVE
WP2402W297-19 WP2402W297-19 LINER, DOOR
74008821 74008821 MODULE-SPK
WP488130 WP488130 NUT
WP3400029 WP3400029 NUT
7103P030-60 7103P030-60 NUT- WING
W10156136 W10156136 ORIFICE
W10156137 W10156137 ORIFICE
W10156836 W10156836 ORIFICE
WP7527P098-60 WP7527P098-60 ORIFICE HO
74008834 74008834 ORIFICE HO
8113P688-60 8113P688-60 OWNERS MANUAL
511873 511873 PAINT
4392900 4392900 PAINT
799344 799344 PAINT
786032 786032 PAINT, BULK (1 QT.) (BLACK (UNCUT))
350942 350942 PAINT, PRESSURIZED SPRAY (12 OZ.) (PRIMER, WHITE)
74009074 74009074 PANEL BAC
74009076 74009076 PANEL BAC
4005P704-51 4005P704-51 PANEL, ACCESS
74011115 74011115 PANEL, MANIFOLD (WHITE)
WP2618F172-69 WP2618F172-69 PANEL, SIDE (2) (BLACK)
WP2618F172-58 WP2618F172-58 PANEL, SIDE (2) (WHITE)
WP2618F172-57 WP2618F172-57 PANEL-CBNT
2416F104-71 2416F104-71 PANEL-DRWR
2416F104-70 2416F104-70 PANEL-DRWR
W10159225 W10159225 PANELDRWR
74011114 74011114 PANLMNFLD
74011116 74011116 PANLMNFLD
W10138349 W10138349 PIPE MANI
3605F146-51 3605F146-51 PLATE
74005783 74005783 PLATE, CONVECTION
WP74008763 WP74008763 RACK- OVEN
WP3406P034-51 WP3406P034-51 RAIL, DRAWER
WP74010551 WP74010551 RECEIVER-
8212471 8212471 REFINISHING MATERIAL (TOUCH-UP SELF-CLEAN(1/2 PT))
12002604 12002604 REGULATOR
3804F316-51 3804F316-51 RETAINER
WP74004078 WP74004078 ROLLER- DR
WP7101P072-60 WP7101P072-60 SCREW
WPY706189 WPY706189 SCREW
WP98008545 WP98008545 SCREW
WP98008544 WP98008544 SCREW
WP74009541 WP74009541 SCREW
WP8273062 WP8273062 SCREW
WP74009857 WP74009857 SCREW
WP4159193 WP4159193 SCREW
WP7101P434-60 WP7101P434-60 SCREW
WP74003976 WP74003976 SCREW
W11233072 W11233072 SCREW
74003975 74003975 SCREW
74005401 74005401 SCREW
74008798 74008798 SCREW
WP3368921 WP3368921 SCREW-TORX
12001655 12001655 SENSOR
WP74005231 WP74005231 SHAFT, STORAGE DRAWER ROLLER
3604F382-09 3604F382-09 SHIELD-HT
WP3604F382-81 WP3604F382-81 SHIELD-HT
WP3604F382-88 WP3604F382-88 SHIELD-HT
WP3604F381-19 WP3604F381-19 SHIELD-VNT
3604F372-51 3604F372-51 SHIELDHT
WP74005546 WP74005546 SPACER- RU
74008690 74008690 SPACER- SI
74008761 74008761 SPACER- SN
4392901 4392901 SPRAY
285006 285006 SPRAY
350930 350930 SPRAY
WP5789A598-60 WP5789A598-60 SPUDS, LP GAS (KIT OF 5)
3807P680-45 3807P680-45 SUPPORT
WP74008252 WP74008252 SWITCH- IN
WP74004224 WP74004224 TAPE
8270P090-60 8270P090-60 TAPE, FOIL (3``)
WP74009014 WP74009014 TAPE- DBL
WP74009025 WP74009025 TAPE- DBL
74010560 74010560 TRIM SIDE
WP3608F092-78 WP3608F092-78 TRIM, LOWER DOOR (BISQUE)
3608F092-70 3608F092-70 TRIM, LOWER DOOR (BLACK)
W10144690 W10144690 TRIM, TOP (WHITE)
WP3608F092-71 WP3608F092-71 TRIM-BOTTM
3608F140-78 3608F140-78 TRIM-DOOR
3608F126-78 3608F126-78 TRIM-DOOR
3608F140-70 3608F140-70 TRIMDOOR
74008830 74008830 TUBING- BR
72017 72017 TUCHUP
4392899 4392899 TUCHUP
72032 72032 TUCHUP
74010751 74010751 VALVE- 16K
WP7502P499-60 WP7502P499-60 VALVE-BRNR
WP7502P500-60 WP7502P500-60 VALVE-BRNR
74008817 74008817 VENT OVEN
