Model Image
Manufacturer

Whirlpool

Model Number

SG1000

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
314561 314561 *NLA*AIRSEAL
912080 912080 *NLA*ARTNOT USED
215437 215437 *NLA*CLIP FOR HARNESS
314807 314807 *NLA*F*TUMBLER BAFFLE - TALL
306072 306072 *NLA*M*ACCESS P
213087 213087 *NLA*M*HOUSING-
310454 310454 *NLA*MANIFOLD, 2 INCH
912083 912083 *NLA*RECEPTACLE
912016 912016 *NLA*RECEPTACLE
WFR314507 WFR314507 75# GAS+EL
314507 314507 75# GASEL
WFR314508 WFR314508 75# LOWER
WFR314504 WFR314504 75# LOWER
WFR314509 WFR314509 75# MAYTAG
WFR314505 WFR314505 75# STEAM
WFR306056 WFR306056 AD-330 S/S
WFR314501 WFR314501 AD-78 BOTT
W10841140 W10841140 ADHESIVE
314523 314523 ADSUP 50
215258 215258 AIR DOME AND TUBE
306086 306086 ANGLE SHUT OFF FOR GAS VALV
314467 314467 BAFFLE - REGULAR
314468 314468 BAFFLE - TALL **NLA*
203274 203274 BASE
WP200835 WP200835 BEARING- B
WP22003441 WP22003441 BEARING- R
WPY312959 WPY312959 BELT
12112425 12112425 BELT
400008 400008 BLOCK, TERMINAL
Y303836 Y303836 BLOWER WHE
W10175939 W10175939 BOLT
W10175938 W10175938 BOLT
W11129403 W11129403 BOLT
Y015629 Y015629 BOLT, GRINDING CHAMBER-DRAI
314501 314501 BOX
314502 314502 BOX
314499 314499 BRACE **NLA*
306128 306128 BRACE FOR STAND-ACCESSO **NLA*
213053 213053 BRACE, TUB
21-1003 21-1003 BRACKET
205908 205908 BRACKET
314508 314508 BRACKET FO
215264 215264 BRACKET FOR WATER VALVE
Y312904 Y312904 BRACKET T
215379 215379 BRACKET, LID SWITCH/DOOR LATCH
WP6-2011900 WP6-2011900 BRAKE-BD
206638 206638 BREAK-SPHN
215245 215245 BRIDGE FOR TOP COVER NA
215247 215247 BUMPER FOR LID
306162 306162 BURNER ASSEMBLY WITH SCREW
215276 215276 BUSHING
308055 308055 CABINET (WHT)
206411 206411 CABINET-WHITE
910768 910768 CABLE STRAP-HARNESS TO BASE
211038 211038 CAP, OIL RETAINER
213044 213044 CENTER SHA
215410 215410 CENTER SHAFT - LARGER
213054 213054 CENTERING SPRING - 3 USED
912075 912075 CIRCUIT BO
WP489503 WP489503 CLAMP
WPW10548433 WPW10548433 CLAMP
WP596669 WP596669 CLAMP
WP3367052 WP3367052 CLAMP
WP285655 WP285655 CLAMP
WP312967 WP312967 CLAMP
200846 200846 CLAMP
WPY303881 WPY303881 CLIP AND I
Y313910 Y313910 CLIP DOOR
Y310376 Y310376 CLIP WIRE
WPY015825 WPY015825 CLIP- MOTO
WP213325 WP213325 CLIP- RETA
912086 912086 CLIPSPEED
306717 306717 CNT. HARNESS MICROPROCESSOR
279834 279834 COIL-VALVE
215415 215415 COLLAR, LOWER
Y014839 Y014839 COLLARDRI
314509 314509 COMBUSTION
Y303368 Y303368 CONE COMB
WP33001048 WP33001048 CONTROL BOARD
306388 306388 CONTROL PANEL
306205 306205 CONVERSION
306206 306206 CONVERSION KIT-LPG TO NAT.
205811 205811 COUNTERWEIGHT
Y313770 Y313770 COVER FOR BLOWER HOUSING
206628 206628 COVER TRA
313915 313915 COVER, THREAD
215579 215579 CUP, BLEACH (WHITE)
WP306604 WP306604 CUT-OFF- T
206849 206849 DC WIRE
211028 211028 DEFLECTOR,WATER (DRIVE TUBE)
212815 212815 DISPENSER CUP
215733 215733 DISPENSING
33001230 33001230 DOOR HINGE
215254 215254 DOOR LATCH HOOK
314077 314077 DOOR SEAL
Y313911 Y313911 DOOR STRIK
306669 306669 DOOR, S1000
015639 015639 DOWEL PIN
WP213045 WP213045 DRAIN HOSE
12002351 12002351 DRIVE MOTOR
W10411000 W10411000 DRIVE MOTOR
12001541 12001541 DRUM ROLLER/WASHER ASSEMBLY.
208847 208847 ELBOW
306637 306637 EXHAUST DU
306064 306064 EXHAUST DUCT **NLA*
8544761A 8544761A EXTEN-EXHT
314481 314481 F*MOUNTING BRACKET
215711 215711 FASTENER
214894 214894 FASTENER, END CAP
314482 314482 FASTENER, SPRING
WP22001650 WP22001650 FASTENER-
312548 312548 FASTENER-ACCESS PANEL TO CA
215075 215075 FASTENERC
W10176519 W10176519 FEET-LVLNG
WPY314137 WPY314137 FOOT- RUBB
314474 314474 FRONT PANEL-WHITE
206550 206550 FRONT PANEL-WHITE
22210632 22210632 GASKET
WP214765 WP214765 GASKET
215374 215374 GASKET FOR BLEACH CUP
WPY013783 WPY013783 GASKET- IN
200813 200813 GEAR CASE COVER ASSEMBLY
203193 203193 GEAR HOUSING W/STUDS & TUBE
204967 204967 GEAR KITP
WP6-2067130 WP6-2067130 GEAR, BEVEL
215278 215278 GLIDE FOR WASHER
204807 204807 GRNDWIRE
211881 211881 GROMMET C
211487 211487 GROOV-PIN
210183 210183 GROOVPIN
213846 213846 GUARD BEL
Y313795 Y313795 GUIDE FOR
314489 314489 GUIDE, PIN
206667 206667 HANDLE WIT
314476 314476 HANDLE,DOOR
WPY306111 WPY306111 HEATER ASSEMBLY COMPLETE
Y306379 Y306379 HEATER ASSM. COMPLETE - 208
314503 314503 HEATER COI
306378 306378 HEATING ELEMENT KIT - 208V
WP303896 WP303896 HI-LIMIT T
W10276607 W10276607 HOSE
WPY215234 WPY215234 HOSE
Y059137 Y059137 HOSE 31/32`` PER FOOT BRANCH ST
WP22003410 WP22003410 HOSE- DRAI
WP213013 WP213013 HOSE- INJE
WP22001448 WP22001448 HOSE- PUMP
WP76314 WP76314 HOSE-FILL
WPY312893 WPY312893 HOUSING, BLOWER
WP6-3033630 WP6-3033630 IDLER ARM
4391996 4391996 IGNITOR
Y303369 Y303369 INLET DUCT
WP216201 WP216201 INLET VALVE
306676 306676 INNER DOOR WITH KNOB
207830 207830 INNER TUB W/PLUG
Y313927 Y313927 INSTRUCTION LABEL
Y313439 Y313439 INSTRUCTION LABEL
WPY313270 WPY313270 INSULATOR FOR HEATER ELEMEN
203725 203725 ISOLATOR
215253 215253 KEY HOLE G
6-2097820 6-2097820 KIT- SHAFT
306508 306508 KIT-BEARNG
203956 203956 KIT-DAMPER
205000 205000 KIT-GLIDE
214743 214743 LABEL
314486 314486 LABEL
214519 214519 LABEL, ELECTRICAL INSTRUCTION
306436 306436 LATCH-DOOR
306073 306073 LEG ASSM, (RT-WHT)
306074 306074 LEG ASSM, LEFT-WHITE
22003428 22003428 LEG, ADJUSTABLE (W/NUT)
206598 206598 LID DOOR LATCH ASSEMBLY
215268 215268 LID DOOR LATCH LEVER
WP206415 WP206415 LID SWITCH
207848 207848 LID SWITCH & DOOR LATCH BRACKET--NA
215378 215378 LID SWITCH LEVER
215269 215269 LID SWITCH LEVER
215251L 215251L LID-ALMOND----NA
215251 215251 LID-WHITE
WP694424 WP694424 LIMITER
211130 211130 LINER- TUB
WPY207427 WPY207427 LINT FILTE
203320 203320 LINT FILTER - DISPENSER
Y313796 Y313796 LINT SEAL
207843 207843 LIP SEAL REPAIR KIT
206417 206417 LOCK SWITCH
210172 210172 LOCK WASHER
206423 206423 LOWER WIRE
211484 211484 LUG WASHER
WP211089 WP211089 LUG- STOP
206420 206420 M*EDGE CONNECTOR ASSEMB **NLA*
314603 314603 MAIN BURNE
Y306083 Y306083 MAIN WIRE HARNESS - GAS
307133 307133 MAIN WIRE HARNESS - SG1000 (
306071 306071 MICROPROCESSOR WIRE HARNESS
215270 215270 MOISTURE B
205133 205133 MOTOR EXTERNAL START SWITCH
WP205999 WP205999 MOTOR MOUNT ASSM COMPLETE
306099 306099 MOTOR PULLEY WITH SET SCREW
214956 214956 MOUNT, MOTOR/UPPER
314532 314532 MOUNTING BRACKET
6-2095720 6-2095720 MOUNTING S
207207 207207 N*CABINET WHT **NLA*
WP213015 WP213015 NOZZLE
WP3400029 WP3400029 NUT
WP112432 WP112432 NUT
WP62739 WP62739 NUT
M0282005 M0282005 NUT
488660 488660 NUT
Y052734 Y052734 NUT
Y052721 Y052721 NUT
WP486255 WP486255 NUT
205529 205529 NUT & BOLT KIT FOR TUB CLAM
WP6-2110472 WP6-2110472 NUT- CLAMP
WP211949 WP211949 NUT- EYEBO
WP33001443 WP33001443 NUT- HEX
WP210385 WP210385 NUT- LOCK
Y052785 Y052785 NUTBRACE
6-0560800 6-0560800 OIL
311640 311640 ORIFICE FOR MAIN BURNER
206405 206405 OUTER TUB
314801 314801 OUTLET DUCT & GRID
306658 306658 OUTLET DUCT & GRID ASSEMBLY
314485 314485 OUTLET DUCT AND GRID
WP210684 WP210684 PAD
314498 314498 PAD DRYER
WP215551 WP215551 PALNUT
214872 214872 PALNUT, END CAP
215249 215249 PALNUT-RETAINER
207205 207205 PANEL, FRONT (WHT)
314475 314475 PANEL, OUTER DOOR (WHT)
WP31001575 WP31001575 PILOT LAMP
213076 213076 PIN FOR PLUG
215539 215539 PIN HOUSING
WPY206629 WPY206629 PIN- COLLA
WPW10221114 WPW10221114 PINION
210054 210054 PINION
210315 210315 PINION
201463 201463 PITMAN WITH WRIST PIN
WP215395 WP215395 PLATE- CLU
306184 306184 PLUG, BLOCKING (LPG REGULATOR)
WP215980 WP215980 PLUG- FILT
215081 215081 POLY BAG
206424 206424 POWER CORD
302521 302521 POWER CORD
22002227 22002227 POWER UNIT
WP6-3037050 WP6-3037050 PULLEY
WP6-2301530 WP6-2301530 PULLEY
WP6-2008160 WP6-2008160 PULLEY- MO
WP6-2022030 WP6-2022030 PUMP AS PA
WP303396 WP303396 RANGE THERMOSTAT
Y312953 Y312953 RECEPTACLE
Y312658 Y312658 RECEPTACLE, SENSOR GROUND WIRE
WPW10133279 WPW10133279 RELAY
WPW10133335 WPW10133335 RELAY (4 CONTACT)
Y312890 Y312890 RETAINER
314716 314716 RETAINER C
W10116752 W10116752 RETAINER-
WPY015667 WPY015667 RETAINING
WP354987 WP354987 RING-E
WP9703438 WP9703438 RING-RETNR
WP210720 WP210720 RIVET
WP33001003 WP33001003 SCREEN
WP96160 WP96160 SCREEN
W10756178 W10756178 SCREW
314554 314554 SCREW
WP33002917 WP33002917 SCREW
WPY310759 WPY310759 SCREW
313764 313764 SCREW
WP8182296 WP8182296 SCREW
215381 215381 SCREW
WP98165 WP98165 SCREW
3400409 3400409 SCREW
WP489399 WP489399 SCREW
WP3934714 WP3934714 SCREW
WP912618 WP912618 SCREW
WP8281227 WP8281227 SCREW
WP67006908 WP67006908 SCREW
WPW10346892 WPW10346892 SCREW
W11164114 W11164114 SCREW
W10850756 W10850756 SCREW
314663 314663 SCREW
WP3177991 WP3177991 SCREW
WPW10139210 WPW10139210 SCREW
WP22001496 WP22001496 SCREW
WPY014874 WPY014874 SCREW
WP27001200 WP27001200 SCREW
W10142650 W10142650 SCREW
WPY313561 WPY313561 SCREW
WP1163839 WP1163839 SCREW
WPW10116751 WPW10116751 SCREW
W11233072 W11233072 SCREW
WP1163283 WP1163283 SCREW
304971 304971 SCREW
WP489128 WP489128 SCREW
214354 214354 SCREW
Y015627 Y015627 SCREW
WP90767 WP90767 SCREW
Y314062 Y314062 SCREW
206478 206478 SCREW & WASHER FOR WASHER AGITATOR
211486 211486 SCREW 3 8
314477 314477 SCREW, ACCESS PANEL
22003235 22003235 SCREW, BEARING INSERT (HEX)
213007 213007 SCREW, CABINET
213501 213501 SCREW, NO.6-20 X 1-1/8 INCH
212951 212951 SCREW, NO.6-32 X 1/4 INCH
053759 053759 SCREW, NO.6-32 X 3/8
210932 210932 SCREW, NO.8 X 9/16 CTSK
211967 211967 SCREW, NO.8-32 X 3/8 INCH
215417 215417 SCREW, TRANSMISSION COVER
WP211232 WP211232 SEAL
WP215233 WP215233 SEAL
WP210286 WP210286 SEAL
WP6-0A57420 WP6-0A57420 SEAL
314286 314286 SEAL FOR F
211001 211001 SEAL FOR LAMP SOCKET
314560 314560 SEAL, MOISTURE
WPY312901 WPY312901 SEAL- BLOW
WP210690 WP210690 SEAL- RUBB
WP314820 WP314820 SEAL- TUMB
WP33313541 WP33313541 SEAL- TUMB
210670 210670 SEGMENT
WP338906 WP338906 SENSOR
304997 304997 SENSOR
Y053241 Y053241 SET SCREW
WP6-3129480 WP6-3129480 SHAFT
314504 314504 SHIELD
314517 314517 SHIELD FOR MICROPROCESSOR
215098 215098 SHIELD, MOTOR
WP22213057 WP22213057 SLEEVE
WP315772 WP315772 SLEEVE
206408 206408 SOCKET AND SEAL ASSEMBLY
206416 206416 SOLENOID
314456 314456 SPACER
22002331 22002331 SPACER
314457 314457 SPACER FOR
306130 306130 SPARK GAP
306070 306070 SPEAKER
215246 215246 SPLASH SHIELD
214434 214434 SPOUT, DEFLECTOR
215273 215273 SPRING CLIP
Y015902 Y015902 SPRING FOR
314473 314473 SPRING FOR IDLER
215292 215292 SPRING FOR SOLENOID
WP215581 WP215581 SPRING- AG
Y306110 Y306110 STAND DRY
314522 314522 STRAIN REL
12001413 12001413 STRAINER & WASHER KIT
215550 215550 STUD FOR L
306054 306054 SUPPORT M
Y303877 Y303877 SWITCH, MOTOR
206505 206505 SWITCH, MOTOR START
205132 205132 SWITCH, MOTOR START
306207 306207 SWITCH, MOTOR START-PROD.
W10169313 W10169313 SWITCH-DOR
202718 202718 TENSION SPRINGS
315275 315275 TERMINAL COVER
Y304596 Y304596 TERMINAL I
306056 306056 THERMISTOR
WP303395 WP303395 THERMOSTAT
306060 306060 THERMOSTAT
WPW10339879 WPW10339879 TIE-WIRE
Y038315 Y038315 TOOL, BRAKE PKG ASSEMBLY
215274 215274 TOP COVER RESTRAINT
206636 206636 TOP COVER-WHITE
206599 206599 TOP COVER-WHITE
306292 306292 TOUCH PAD
6-2097750 6-2097750 TRANS DEE
306062 306062 TRANSFORMER
215266 215266 TRIM, FRONT PANEL **NLA*
6-2040130 6-2040130 TUB BEARIN
206406 206406 TUB COVER ASSEMBLY
WP215235 WP215235 TUBE
WP214495 WP214495 TUBE, INLET TO TUB
33001177 33001177 TUMBLER
314469 314469 TUMBLER **NLA*
314806 314806 TUMBLER BAFFLE - SHORT
Y306664 Y306664 TUMBLER COMPLETE
306710 306710 TUMBLER FR
210866 210866 TWIN SPEED
215232 215232 UNBALANCE BUMPER
202476 202476 UNBALANCE SWITCH
306084 306084 VALVE, GAS
912006 912006 WASHER
WP312535 WP312535 WASHER
WP314158 WP314158 WASHER
WPY312527 WPY312527 WASHER
310557 310557 WASHER
201379 201379 WASHER AGITATOR - BLACK
22002124 22002124 WASHER AGITATOR SHAFT
WP207538 WP207538 WASHER AGITATOR W
215394 215394 WASHER BE
213073 213073 WASHER DO
Y054867 Y054867 WASHER LO
211100 211100 WASHER, CUSHION
911852 911852 WASHER, LOCK (BRACE)
212979 212979 WASHER, TUB BRACE
WP211210 WP211210 WASHER,CLAMPING NUT(STAINLESS)
WP6-2114830 WP6-2114830 WASHER- SP
WP22003555 WP22003555 WASHER- ST
WPY311270 WPY311270 WASHER- TE
WPY015666 WPY015666 WASHER-RET
211500 211500 WASHERBRA
Y014827 Y014827 WASHERCEN
WP206418 WP206418 WATER LEVE
WP206413 WP206413 WATER VALV
211723 211723 WINDOW FOR TUB
901220 901220 WIRE GROU
206422 206422 WIRE HARNE
WP306090 WP306090 WIRE HARNESS
215272 215272 WIRE TIE
WP6-2066850 WP6-2066850 YOKE
Main Menu x
