Model Image
Manufacturer

Whirlpool

Model Number

WFE374LVS0

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
241430 241430 ACCESSORY PARTS, ALUMINUM FOIL
W11447673 W11447673 ANCHOR-TIP
W10217760 W10217760 BEZEL, KEEP WARM (WHITE)
W10184164 W10184164 BEZEL-SWTH
W10217758 W10217758 BEZEL-SWTH
WPW10245259 WPW10245259 BLOCK-TERM
W10525121 W10525121 BRACKET, CONSOLE MOUNTING
9762078 9762078 BRACKET, MOUNTING EOC
WPW10462912 WPW10462912 BRKT-MNTG
W11728255 W11728255 BRKT-SRVCE
W11502236 W11502236 BRKT-SUPRT
W10404688 W10404688 BRKT-SUPRT
9758490 9758490 BUTTON, KEEP WARM (BISCUIT)
9758491 9758491 BUTTON, KEEP WARM (BLACK)
9757492 9757492 BUTTON, KEEP WARM (WHITE)
WP3196068 WP3196068 CAMERA LENS-LIGHT
W10646923 W10646923 CARD, INSULATOR
W10355051 W10355051 CLEANER, COOKTOP
WP8273564 WP8273564 CLIP
W10183541 W10183541 CLIP
W10137382 W10137382 CLIP
W10787766 W10787766 CLIP
9761517 9761517 CLIP, DOOR MOUNTING
3196200 3196200 CLIP, SPRING
WPW10476353 WPW10476353 CONTROL BOARD
WPW10173525 WPW10173525 CONTROL BOARD
W10250721 W10250721 COOKTOP
W10250718 W10250718 COOKTOP
W10239443 W10239443 COOKTOP
WPW10326122 WPW10326122 COVER-BLCK
WP8272473 WP8272473 COVER-REAR
W10289149 W10289149 COVER-REAR
WPW10107820 WPW10107820 DOOR DOOR LATCH
WP9761013 WP9761013 DOOR DOOR LATCH
W10817434 W10817434 DOOR HANDLE
WPW10144883 WPW10144883 DOOR HANDLE
WPW10323589 WPW10323589 DOOR HANDLE
WPW10299224 WPW10299224 DOOR HINGE
WPW10299227 WPW10299227 DOOR HINGE
WP8523175 WP8523175 DOOR TRIM
WP8523177 WP8523177 DOOR TRIM
WP8523178 WP8523178 DOOR TRIM
WP8523166 WP8523166 DOOR TRIM
W10761018 W10761018 DOOR TRIM
WP8523173 WP8523173 DOOR TRIM
WP8523172 WP8523172 DOOR TRIM
WP8523167 WP8523167 DOOR TRIM
W10761014 W10761014 DOOR TRIM
W10296838 W10296838 DRAWR-UTIL
WP9755770 WP9755770 ELMNT-BAKE
W10856603 W10856603 ELMNT-BROL
WPW10583047 WPW10583047 ELMNTBROL
W11219665 W11219665 ENDCAP-PNL
W11219664 W11219664 ENDCAP-PNL
W11219365 W11219365 ENDCAP-PNL
W11230611 W11230611 ENDCAP-PNL
W11230612 W11230612 ENDCAP-PNL
WPW10058460 WPW10058460 FOOT-LEVEL
WPW10341186 WPW10341186 FOOT-LEVEL
WPW10316950 WPW10316950 FRAME-WNDW
WP3196548 WP3196548 FUSE-THRML
W11542153 W11542153 GASKT-DOOR
WPW10118454 WPW10118454 GLASS DOOR
WPW10330077 WPW10330077 GLASS DOOR
WPW10118455 WPW10118455 GLASS DOOR
WP8053948 WP8053948 GLASS DOOR
WP8053334 WP8053334 GLIDE-DRWR
WPW10114344 WPW10114344 GLIDE-DRWR
W10465644 W10465644 HARNESS, HIDDEN BAKE
W11172524 W11172524 HARNS-WIRE
W11134592 W11134592 HARNS-WIRE
W10251760 W10251760 HARNS-WIRE
W10322364 W10322364 HARNS-WIRE
W10322357 W10322357 HARNS-WIRE
W10647259 W10647259 HINGE-RECV
WPW10149355 WPW10149355 INFINITE CONTROL SWITCH
WP3149404 WP3149404 INFINITE CONTROL SWITCH
W10252706 W10252706 INSTRUCTIONS, INSTALLATION
WPW10278991 WPW10278991 INSULATION
WPW10208653 WPW10208653 INSULATION
W10182346 W10182346 INSULATION
W10326347 W10326347 INSULATION
W11684918 W11684918 INSULATION
WP9761963 WP9761963 KNOB
WP9761964 WP9761964 KNOB
WP9761962 WP9761962 KNOB
8009 8009 LIGHT BULB
WP8523265 WP8523265 LIGHT-IND
WP9761344 WP9761344 LINER-DOOR
W10209617 W10209617 NAMEPLATE
WP7103P027-60 WP7103P027-60 NUT
W10200357 W10200357 OWNERS MANUAL
799344 799344 PAINT, BULK (1 QT. WHITE)
285006 285006 PAINT, PRESSURIZED SPRAY (12 OZ. BLACK)
350930 350930 PAINT, PRESSURIZED SPRAY (12 OZ. WHITE)
350942 350942 PAINT, PRESSURIZED SPRAY (12 OZ.) (PRIMER, WHITE)
511873 511873 PAINT, TOUCH-UP (1/2OZ. WHITE PORCELAIN (2 OZ.))
72017 72017 PAINT, TOUCH-UP (1/2OZ. WHITE)
W10170526 W10170526 PAN
W10170628 W10170628 PANEL, CONTROL (BISCUIT)
WPW10170662 WPW10170662 PANEL, CONTROL (BLACK)
WPW10237657 WPW10237657 PANEL-DRWR
W11219377 W11219377 PANEL-DRWR
W11230488 W11230488 PANEL-DRWR
WPW10575396 WPW10575396 PANEL-SIDE
WPW10162245 WPW10162245 PANEL-SIDE
W10170661 W10170661 PANL-CNTRL
W10183213 W10183213 PANL-CNTRL
WP3195060 WP3195060 PIN-COOKTP
WPW10256908 WPW10256908 RACK-OVEN
9761368 9761368 RAIL, BASE (LEFT)
WP9761367 WP9761367 RAIL, BASE (RIGHT)
8212471 8212471 REFINISHING MATERIAL (TOUCH-UP SELF-CLEAN(1/2 PT))
W11539580 W11539580 RETAINER
W10465685 W10465685 RETAINER
W10134121 W10134121 RETAINER
W10134125 W10134125 RETAINER
W10450380 W10450380 RETAINER, INSULATION
WP3196814 WP3196814 RIVET
WP3196813 WP3196813 RIVET
9757239 9757239 ROD, DOOR SWITCH
W10078380 W10078380 ROD-LATCH
9761301 9761301 SCREEN, VENT
WP3196154 WP3196154 SCREW
W11244557 W11244557 SCREW
WPW10200660 WPW10200660 SCREW
WPW10031790 WPW10031790 SCREW
W10491985 W10491985 SCREW
W10817436 W10817436 SCREW
3148604 3148604 SCREW
WP489491 WP489491 SCREW
WP3400016 WP3400016 SCREW
W10777162 W10777162 SCREW
WP3196174 WP3196174 SCREW
WP3196175 WP3196175 SCREW
3196172 3196172 SCREW
W11169708 W11169708 SCREW
WPW10067840 WPW10067840 SCREW
WP3400882 WP3400882 SCREW
W11233072 W11233072 SCREW
WP3400832 WP3400832 SCREW
3196166 3196166 SCREW (WHITE)
3400964 3400964 SCREW, GROUND
8522414 8522414 SEAL, WINDOW
W10010350 W10010350 SEAL-OVEN
WPW10181986 WPW10181986 SENSOR
W10134247 W10134247 SHIELD-HT
W11594027 W11594027 SOCKT-LITE
W10877054 W10877054 SPACER
W10823711 W10823711 SURFACE ELEMENT
W11517959 W11517959 SURFACE ELEMENT
WP9762851 WP9762851 SURFACE ELEMENT
WP8272820 WP8272820 SWITCH-PB
WP9757262 WP9757262 SWTCH-LITE
W10384450 W10384450 TECH SHEET
9757143 9757143 TEMPLATE, ANTI-TIP (ENGLISH/FRENCH)
9757142 9757142 TEMPLATE, ANTI-TIP (ENGLISH/SPANISH)
9762761 9762761 TIPS, SAFE COOKING (ENGLISH)
W10183712 W10183712 TRAY-BAKE
WPW10310922 WPW10310922 TRIM-VENT
W10817433 W10817433 TRIM-VENT
WPW10134285 WPW10134285 TUBE-VENT
3184020 3184020 WIRE, GROUND
313660 313660 WIRING HARNESS PARTS, CLIP, GROUND WIRE
