Model Image
Manufacturer

Whirlpool

Model Number

WOC54EC0AS03

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
W10283031 W10283031 "CHASSIS, COVER TOP BACK 30"""
W10318158 W10318158 "CHASSIS, COVER TOP FRONT 30"""
4396923 4396923 ACCESSORIES, BROILER PAN AND GRID
W10355010 W10355010 ACCESSORIES, CLEANER, KITCHEN & APPLIANCE
W11042467 W11042467 ACCESSORIES, CLEANER, STAINLESS STEEL
W10123240 W10123240 ACCESSORIES, RACK, BROILER PAN AND ROASTING
8205262RB 8205262RB ACCESSORIES, STEAMER, MICROWAVE
WP482338 WP482338 ADHESIVE
W11214480 W11214480 ARM
WPW10128850 WPW10128850 ARM
W10327379 W10327379 ASSEMBLY, HANDLE (BLACK)
W10327380 W10327380 ASSEMBLY, HANDLE (WHITE)
W10813703 W10813703 BACK, CHASSIS
W11238787 W11238787 BASE, CHASSIS
W10616809 W10616809 BASE, VENT EXHAUST
WPW10661038 WPW10661038 BLOWER
W10655463 W10655463 BRACKET, BLOWER (LEFT)
W10655462 W10655462 BRACKET, BLOWER (RIGHT)
W10407600 W10407600 BRACKET, DOOR
W11025615 W11025615 BRKT-GLASS
W10853628 W10853628 BRKT-GLASS
W10812024 W10812024 BRKT-GLASS
WPW10351278 WPW10351278 BUMPER
W11193483 W11193483 CAMERA LENS-LAMP
WPW10412722 WPW10412722 CAMERA LENS-LIGHT
8304588BL 8304588BL CAP, SCREW
W10618126 W10618126 CHASSIS, BACK DIVIDER
W10655467 W10655467 CHASSIS, COMBO SIDE
W10655466 W10655466 CHASSIS, COMBO SIDE (LEFT)
W10283029 W10283029 CHASSIS, COMBO SIDE (RIGHT)
4448664 4448664 CLAMP, CONDUIT
W10190263 W10190263 CLIP, HARNESS
W10120231 W10120231 CLIP, SPRING
4450950 4450950 CONDUIT, COMBO
WPW10586836 WPW10586836 CONTROL BOARD
WPW10412514 WPW10412514 CONTROL BOARD
W10852640 W10852640 CONTROL BOARD
WPW10752316 WPW10752316 CONTROL BOARD
W10864182 W10864182 CONTROL PANEL
W10864180 W10864180 CONTROL PANEL
W10864178 W10864178 CONTROL PANEL
W10519707 W10519707 COVER, BACK DUCT
W10519703 W10519703 COVER, BACK DUCT
8285593 8285593 COVER, CONNECTOR
W10356437 W10356437 COVER, SLOT MODULE
W10616810 W10616810 COVER, VENT EXHAUST
W10915651 W10915651 COVER-PLT
WPW10283008 WPW10283008 COVR-ACESS
W11676353 W11676353 COVR-MOTOR
W10282957 W10282957 CROSSBAR, HIDDEN BAKE TRAY
W10904163 W10904163 DEFLECTOR, BLOWER
W10827059 W10827059 DOOR
W10883049 W10883049 DOOR DOOR LATCH
WPW10317136 WPW10317136 DOOR HANDLE
W10874474 W10874474 DOOR HINGE
W10825778 W10825778 DOOR HINGE
W11545804 W11545804 ELMNT-BAKE
WPW10260252 WPW10260252 ELMNT-BROL
W11398764 W11398764 FILTER
W10359769 W10359769 FOAM, HANDLE
N_P N_P FOLLOWING PARTS NOT ILLUSTRATED
WPW10709147 WPW10709147 FRAME-GLAS
WPW10017410 WPW10017410 FUSE
W11188752 W11188752 FUSE
W11623080 W11623080 GASKET-OVN
W10577914 W10577914 GLASS DOOR
W10577920 W10577920 GLASS DOOR
W10829928 W10829928 GLASS DOOR
W10577911 W10577911 GLASS DOOR
W10577917 W10577917 GLASS DOOR
W10577915 W10577915 GLASS DOOR
WPW10347596 WPW10347596 GLASS DOOR
W10759525 W10759525 GROMMET
W10798191 W10798191 GUIDE, USE & CARE (MICROWAVE OVEN)
W10796009 W10796009 GUIDE, USE & CARE (OVEN)
W11157222 W11157222 HARNESS, COMMUNICATION
W10573327 W10573327 HARNESS, DOOR DOOR LATCH
W10389372 W10389372 HARNESS, FAN & TURNTABLE
W10874060 W10874060 HARNESS, INVERTER
W10778560 W10778560 HARNESS, MAIN
W11613828 W11613828 HINGE-RECV
4454949 4454949 HOLDER, FUSE
W10245194 W10245194 HOLDER, FUSE
WPW10490593 WPW10490593 HOUSNG-LMP
W10696163 W10696163 INSTRUCTIONS, INSTALLATION
W11688731 W11688731 INSULATION
W11684789 W11684789 INSULATION
W11033422 W11033422 INTERLOCK
WP8205683 WP8205683 INTERLOCK
W10217711 W10217711 INVERTER
WPW10412711 WPW10412711 LIGHT BULB
WPW10734063 WPW10734063 LIGHT-IND
W10886919 W10886919 LMP-BASLES
W11684570 W11684570 MICROWAVE DOOR
W11346197 W11346197 MICROWAVE MAGNETRON
W11356970 W11356970 MISCELLANEOUS PARTS, HARNESS, INTERLOCK
W11344874 W11344874 MOTOR-FAN
W10911403 W10911403 MOTOR-TURN
W11178521 W11178521 NAMEPLATE
WP488130 WP488130 NUT
285006 285006 PAINT, PRESSURIZED SPRAY (12OZ. BLACK)
261900 261900 PAINT, SPRAY (CITRINE WHITE)
350930 350930 PAINT, SPRAY (WHITE)
72032 72032 PAINT, TOUCH-UP (1/2OZ. BLACK)
72017 72017 PAINT, TOUCH-UP (1/2OZ. WHITE)
W11218798 W11218798 RACK-OVEN
W10360516 W10360516 RAIL, SIDE (LEFT)
W10360518 W10360518 RAIL, SIDE (RIGHT)
W11568584 W11568584 RANGE THERMOSTAT
WP4449751 WP4449751 RANGE THERMOSTAT
423107022541 423107022541 REFLECTOR
W11110134 W11110134 RING-TURN
WPW10120235 WPW10120235 ROD-REL
W11233072 W11233072 SCREW
W11684512 W11684512 SCREW
461967825971 461967825971 SCREW
461967825321 461967825321 SCREW
W11347848 W11347848 SCREW
WP98008545 WP98008545 SCREW
WP3196183 WP3196183 SCREW
WP7101P434-60 WP7101P434-60 SCREW
WP90767 WP90767 SCREW
WP12990527 WP12990527 SCREW
4450800 4450800 SCREW, GROUNDING
W10491987 W10491987 SEAL-FOAM
W11699906 W11699906 SENSOR
W11233913 W11233913 SENSOR
W10859573 W10859573 SENSOR
W11179756 W11179756 SHAFT-TURN
W10796080 W10796080 SHEET, TECH
W10283024 W10283024 SIDE, BRACKET
W10318190 W10318190 SIDE, CHASSIS
W11240831 W11240831 SPACER
W10351308 W10351308 SPACER, CHASSIS BOTTOM DUCT
W10618105 W10618105 SPACER, LATERAL
W10347649 W10347649 SPACERS, FRONT
W11700292 W11700292 SPRING
W10465869 W10465869 SPRING, LAMP
W11226264 W11226264 STRAP, GROUND
W11684510 W11684510 SUPPORT
W10213759 W10213759 SUPPORT, AIR CHANNEL
W10283020 W10283020 SUPPORT, BASE (LEFT)
W10283021 W10283021 SUPPORT, BASE (RIGHT)
8205707 8205707 SUPPORT, BOTTOM
W10283022 W10283022 SUPPORT, CROSSBAR
W10356644 W10356644 SUPPORT, MICROWAVE MODULE
W10211972 W10211972 SWITCH, MICRO V15T16-CZ200
W10813743 W10813743 TOP, CHASSIS
W11238401 W11238401 TRANSFORMR
W10318198 W10318198 TRAY, HIDDEN BAKE
W10818723 W10818723 TRAY-COOK
W10510106 W10510106 TRIM
W10486208 W10486208 TRIM, SIDE LEFT
W11240525 W11240525 TUBE-VENT
W10283042 W10283042 VENT, COMBO CENTER
461968973241 461968973241 VENT, TOP MICROWAVE
WPW10351279 WPW10351279 VENT-OVEN
WPW10327373 WPW10327373 VENT-OVEN
