Model Image
Manufacturer

Whirlpool

Model Number

WRF560SMYM04

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
876029 876029 "KIT, FOAM SLAB (30"" X 32 1/2"" X 1 1/2"")"
W11508229 W11508229 AIR-TOWER
W11227949 W11227949 AIR-TOWER
W10311524 W10311524 ANTIBACTERIAL FILTER
WP627843 WP627843 ARM-EJECTR
WPW10474785 WPW10474785 ARM-SHUT
WPW10122563 WPW10122563 ARM-STRIPR
WPW10257246 WPW10257246 AXLE
W11594405 W11594405 AXLE
WP2315541 WP2315541 BAFFLE-AIR
W10349514 W10349514 BAFFLE-AIR
606755 606755 BAG
WPW10317289 WPW10317289 BASKET-FZR
WPW10555437 WPW10555437 BASKET-FZR
WP627985 WP627985 BIMETL-DEF
WPW10326335 WPW10326335 BIN CONTROL LEVER
WPW10308869 WPW10308869 BIN CONTROL LEVER
W11106787 W11106787 BIN-CNTLVR
WPW10139483 WPW10139483 BLADE-FAN
WP2163777 WP2163777 BLADE-FAN
W11500948 W11500948 BRACKET
W11745278 W11745278 BRACKET
W10314197 W10314197 BRACKET
2254454 2254454 BRACKET, EVAPORATOR FAN REAR
WPW10470155 WPW10470155 CAM-DOOR
WPW10313918 WPW10313918 CAMERA LENS-LIGHT
WPW10662129 WPW10662129 CAPACITOR
WP4317852 WP4317852 CEMENT, ALUMILASTIC (1 1/4 OZ.)
W10861184 W10861184 CLAMP
549193 549193 CLAMP, POWER CORD
WP2315522 WP2315522 CLIP
WP628379 WP628379 CLIP
W10683556 W10683556 CLIP
W10296661 W10296661 CLIP
W11501419 W11501419 CLIP
W10331226 W10331226 CLIP
W11661170 W11661170 CLIP
2219077 2219077 CLIP, HARNESS
WPW10277361 WPW10277361 COLLAR
WPW10507886 WPW10507886 COMPRESSOR
WPW10342567 WPW10342567 CONDENSER
WPW10317224 WPW10317224 CONTAINER
W10798439 W10798439 CONTAINER, WATER RESERVOIR
W11035836 W11035836 CONTROL BOARD
W11082837 W11082837 CONTROL BOARD
WPW10425252 WPW10425252 COVER
WPW10356895 WPW10356895 COVER
W11133099 W11133099 COVER
W10413160 W10413160 COVER
W10336009 W10336009 COVER
W10465764 W10465764 COVER
W10465767 W10465767 COVER
W10465770 W10465770 COVER
W10465771 W10465771 COVER
W10465768 W10465768 COVER
W10300900 W10300900 COVER, EVAPORATOR
W10465765 W10465765 COVER, HINGE (LEFT HAND (WHITE))
W10313215 W10313215 COVER-BOX
WPW10306392 WPW10306392 COVER-FILT
W10360550 W10360550 COVER-FRNT
W10636716 W10636716 COVER-UNIT
WPW10317184 WPW10317184 CRISPER PAN
WPW10370327 WPW10370327 CRISPER PAN
W11676540 W11676540 CUP-FILL
WPW10257451 WPW10257451 DAMPER
LW10433607 LW10433607 DOOR ASSEMBLY BL
LW10413518 LW10413518 DOOR ASSEMBLY BL
LW10413522 LW10413522 DOOR ASSEMBLY BL
LW10433608 LW10433608 DOOR ASSEMBLY MS
LW10413519 LW10413519 DOOR ASSEMBLY MS
LW10413524 LW10413524 DOOR ASSEMBLY MS
LW10433606 LW10433606 DOOR ASSEMBLY WH
LW10353181 LW10353181 DOOR ASSEMBLY WH
LW10393587 LW10393587 DOOR ASSEMBLY WH
WPW10521409 WPW10521409 DOOR HINGE
WPW10521411 WPW10521411 DOOR HINGE
WPW10624450 WPW10624450 DRAWER SLIDE RAIL
WPW10624451 WPW10624451 DRAWER SLIDE RAIL
W10843121 W10843121 DRIER-TUBE
WPW10353932 WPW10353932 ENDCAP-GRL
WPW10339257 WPW10339257 ENDCAP-GRL
W10353930 W10353930 ENDCAP-GRL
W10727388 W10727388 ENERGY GUIDE
WPW10321158 WPW10321158 EVAPORATOR
WPW10464673 WPW10464673 EVAPORATOR MOTOR
W10851579 W10851579 FILLER
WPW10283959 WPW10283959 FILLER
W11252732 W11252732 FILLER
EDR2RXD1 EDR2RXD1 FILTER
WPW10601149 WPW10601149 FITTING
WPW10289690 WPW10289690 FRONT COVER
W10849448 W10849448 GASKET
WP1106508 WP1106508 GASKET
W10836785 W10836785 GASKET ASSEMBLY
W11625017 W11625017 GASKET ASSEMBLY
W10460611 W10460611 GASKET ASSEMBLY
WPW10460580 WPW10460580 GASKET ASSEMBLY
W10460610 W10460610 GASKET ASSEMBLY
W10460612 W10460612 GASKET ASSEMBLY
WPW10513681 WPW10513681 GLASS SHELF
WPW10313893 WPW10313893 GLASS SHELF
WPW10486290 WPW10486290 GLASS SHELF
WP542638 WP542638 GREASE
WPW10330850 WPW10330850 GRILLE
WPW10353935 WPW10353935 GRILLE
WPW10353933 WPW10353933 GRILLE
WPW10300127 WPW10300127 GRILLE
WPW10169124 WPW10169124 GROMMET
W10852725 W10852725 GROMMET
WP2264462 WP2264462 GROMMET
W10830683 W10830683 HANDLE
W10865840 W10865840 HANDLE
W11459378 W11459378 HANDLE
W10830136 W10830136 HANDLE
W10686483 W10686483 HANDLE
W10830130 W10830130 HANDLE
W11643622 W11643622 HARNS-WIRE
W10390445 W10390445 HARNS-WIRE
W10421350 W10421350 HARNS-WIRE
W10856574 W10856574 HEAT-PROBE
WPW10436849 WPW10436849 HEATER
W10546298 W10546298 HINGE-DOOR
W11573371 W11573371 HINGE-DOOR
WPW10314204 WPW10314204 HOUSING
WPW10313917 WPW10313917 HOUSING
WPW10435577 WPW10435577 HOUSING
W10844267 W10844267 HOUSING
W11605789 W11605789 HOUSING
2323186 2323186 HOUSING
W10469878 W10469878 HOUSING
WP2195914 WP2195914 HOUSING-IM
4317943 4317943 ICEMAKER ASSEMBLY
2225623 2225623 ICEMAKER SERVICE SHEET
WPW10279909 WPW10279909 INLET VALVE
4387491 4387491 INSERT, TUBE
W11553819 W11553819 INSULATION
WPW10141622 WPW10141622 LEVELER
W11518235 W11518235 LIGHT BULB
876370 876370 MISCELLANEOUS, INSULATION (2 PIECES, 3`` X 24`` X 48``)
WPW10360497 WPW10360497 MODULE
8201515 8201515 MODULE ASSEMBLY (INCLUDES ITEMS 21 & 22)
WPW10190929 WPW10190929 MOLD-ICE
WP2188874 WP2188874 MOTOR-COND
W11178521 W11178521 NAMEPLATE
W10850162 W10850162 ORIFICE
4392900 4392900 PAINT, BULK (1 QT. BISCUIT/BISQUE)
799344 799344 PAINT, BULK (1 QT. WHITE)
4392901 4392901 PAINT, PRESSURIZED SPRAY (12 OZ. BISCUIT/BISQUE)
285006 285006 PAINT, PRESSURIZED SPRAY (12OZ. BLACK)
350942 350942 PAINT, SPRAY (12-OZ. WHITE PRIMER)
350930 350930 PAINT, SPRAY (WHITE)
4392899 4392899 PAINT, TOUCH-UP (1/2OZ. BISCUIT/BISQUE)
72032 72032 PAINT, TOUCH-UP (1/2OZ. BLACK)
511873 511873 PAINT, TOUCH-UP (1/2OZ. WHITE PORCELAIN (2 OZ.))
72017 72017 PAINT, TOUCH-UP (1/2OZ. WHITE)
W10890667 W10890667 PAN-DRIP
WPW10378263 WPW10378263 PAN-ICE
WPW10397907 WPW10397907 PAN-MEAT
WP2174706 WP2174706 PIN-HITCH
WP939101 WP939101 PLATE
W10300116 W10300116 PLATE
W10346771A W10346771A PRO PRSERV
W11210990 W11210990 RAIL
W11581314 W11581314 RAIL
N_P N_P RAIL, CENTER (NOT SERVICED)
W11692845 W11692845 RAIL-MULLN
W11164152 W11164152 ROLLER
WPW10475495 WPW10475495 ROLLER-CAB
WPW10359255 WPW10359255 ROLLER-CAB
WPW10359256 WPW10359256 ROLLER-CAB
489136 489136 SCREW
W11544659 W11544659 SCREW
WP489128 WP489128 SCREW
WPW10171469 WPW10171469 SCREW
W11501418 W11501418 SCREW
WP3400203 WP3400203 SCREW
WPW10170540 WPW10170540 SCREW
W10854958 W10854958 SCREW
WP488163 WP488163 SCREW
WP489478 WP489478 SCREW
WP489442 WP489442 SCREW
WP489497 WP489497 SCREW
WP488729 WP488729 SCREW
WP681249 WP681249 SCREW
W10001280 W10001280 SCREW
WP503695 WP503695 SEALER
WP505587 WP505587 SEALER
212643 212643 SEALER, GUM (4 FEET)
W10596092 W10596092 SERVICE AND WIRING SHEET
W10371538 W10371538 SHAFT
WPW10502933 WPW10502933 SHELF-CANT
WPW10314195 WPW10314195 SHIELD
WPW10450363 WPW10450363 SHIM
WPW10397635 WPW10397635 SLIDE
WPW10397636 WPW10397636 SLIDE
W11590562 W11590562 SLIDE
W10411411 W10411411 SLIDE
W11661565 W11661565 SOCKET
WPW10448874 WPW10448874 START-DEV
W10236396 W10236396 STRAP
W11241829 W11241829 SUPPORT
W11384469 W11384469 SWITCH
W11396033 W11396033 SWITCH
W11238399 W11238399 TAPE
W11724692 W11724692 THERMISTOR
WPW10383615 WPW10383615 THERMISTOR
W11544568 W11544568 THIMBLE
W11189115 W11189115 THIMBLE
WPW10339879 WPW10339879 TIE-WIRE
WP1117510 WP1117510 TORX SCREW WRENCH, TORX KEY
WPW10468555 WPW10468555 TRACK
WPW10468556 WPW10468556 TRACK
WPW10468557 WPW10468557 TRACK
W11676464 W11676464 TUBE
W10510988 W10510988 TUBE
W11190084 W11190084 TUBE-DRAIN
W10449880 W10449880 TUBE-WATER
W10360467 W10360467 USE AND CARE GUIDE
WP978025 WP978025 VALVE
978030 978030 VALVE, ACCESS
978029 978029 VALVE, ACCESS
978028 978028 VALVE, ACCESS
978027 978027 VALVE, ACCESS
978026 978026 VALVE, ACCESS
876764 876764 VALVE, ACCESS
EDR1RXD1 EDR1RXD1 WATER FILTER
WPW10496649 WPW10496649 WATER TUBE
WPW10449611 WPW10449611 WATER TUBE
WPW10424230 WPW10424230 WIRE HARNESS
WPW10487766 WPW10487766 WIRE HARNESS
