Model Image
Manufacturer

Whirlpool

Model Number

WUB50X24HZ01

Description

Beverage Center

Interactive Exploded View
Exploded View

Parts List

Part Number Description
W11369466 W11369466 ASSEMBLY, DOOR
W11264700 W11264700 BASE-UNIT
W11265575 W11265575 BRACE
W11264669 W11264669 BRACKET
W11266075 W11266075 CLAMP
W10270517 W10270517 CLIP
W11266079 W11266079 CLOSER
W11726396 W11726396 COMPRESSOR
W10772873 W10772873 COMPRESSOR
W11312540 W11312540 CONTRL-BOX
W11476540 W11476540 CONTRL-BOX
W11311792 W11311792 CONTROL
W11265410 W11265410 CORD-POWER
W10772885 W10772885 COVER RELAY
W11264703 W11264703 COVER-BACK
W11301448 W11301448 DOOR
W10163273 W10163273 DRIER TUBE
W11312455 W11312455 FAN COVER AS
N_P N_P FOLLOWING PARTS NOT ILLUSTRATED
W11315259 W11315259 GASKET-DOR
W11700300 W11700300 GRILLE
W11265408 W11265408 HANDLE
W11263876 W11263876 HARNS-WIRE
W11265404 W11265404 HEATER
W11312624 W11312624 HINGE, BOTTO
W11264668 W11264668 HINGE-DOOR
W11106296 W11106296 LEG, LEVELIN
W11312450 W11312450 LENS-LIGHT
W11263841 W11263841 LENS-LIGHT
W11266081 W11266081 MOTOR-EVAP
W10780361 W10780361 OVERLOAD RELEASE
W11264698 W11264698 PAN-DRIP
W11372322 W11372322 PAS - CONTRO
W11313209 W11313209 PCB BOX
W11313206 W11313206 PCB COVER
W11263339 W11263339 PLATE
WP4344779 WP4344779 REFRIGERATOR COMPRESSOR GROMMET
W10772895 W10772895 RUNNING CAPACITOR
W11675284 W11675284 SCREW
4344796 4344796 SCREW
W11371101 W11371101 SCREW
W11371100 W11371100 SCREW
W11371097 W11371097 SCREW
W11371103 W11371103 SCREW
W11371345 W11371345 SCREW
W10243123 W10243123 SCREW
W10319186 W10319186 SCREW
W11371341 W11371341 SCREW
4344797 4344797 SCREW
W11375763 W11375763 SCREW
W11265577 W11265577 SEAL
W11311791 W11311791 SHELF GLASS
W11311388 W11311388 SHELF, SUPPORT
W11266373 W11266373 SHELF-GLAS
W11312648 W11312648 STOPPER, DOOR
W11179356 W11179356 STUD-HNDLE
W11311389 W11311389 SUPPORT
W11313093 W11313093 SUPPORT
W11266082 W11266082 SWITCH
W11359415 W11359415 TEMP FUSE AS
W11266076 W11266076 THERMISTOR
W11312550 W11312550 TRIM
W11265406 W11265406 WASHER
W10322070 W10322070 WASHER
W11312493 W11312493 WINE RACK
W11312494 W11312494 WINE RACK
W11265588 W11265588 WIRE
4344829 4344829 WIRE TIE
W11489778 W11489778 WRAP, DOOR (STAINLESS)
