Model Image
Manufacturer

Whirlpool

Model Number

YWMH31017HW2

Description

Microwave/hood Combo

Interactive Exploded View
Exploded View

Parts List

Part Number Description
W11441128 W11441128 300CFM HOOD
W10827115 W10827115 BASE
W10313275 W10313275 BRACKET SUPPORT
W11265233 W11265233 CAPACITOR BRACKET
W11446916 W11446916 CASE, OUTER (BLACK)
W11252184 W11252184 CONTROL PANEL
W11252185 W11252185 CONTROL PANEL
W11293488 W11293488 COVER, RIGHT DUCT
W11238817 W11238817 COVER, WAVEGUIDE
W11302941 W11302941 COVER-SIDE
W10571179 W10571179 CUSHION
W10471570 W10471570 DEFLECTOR ARM
W10138797 W10138797 DUCT COVER
W10828030 W10828030 DUCT-AIR
W10827148 W10827148 GUIDE-AIR
W11305127 W11305127 HANDLE (BLACK)
W11322771 W11322771 HANDLE (STAINLESS)
W11305129 W11305129 HANDLE (WHITE)
W11252187 W11252187 INTERLOCK
W11252186 W11252186 INTERLOCK
W11459357 W11459357 MAIN HARNESS
W10245196 W10245196 MICROWAVE BASE PLATE ASSEMBLY
W10892387 W10892387 MICROWAVE CHARCOAL FILTER
W11175576 W11175576 MICROWAVE CONTROL PANEL ASSEMBLY
W10833365 W10833365 MICROWAVE CONTROL PANEL BRACKET
W10833531 W10833531 MICROWAVE CONTROL PANEL SEAL
W11247223 W11247223 MICROWAVE DOOR ASSEMBLY (BLACK)
W11173813 W11173813 MICROWAVE DOOR ASSEMBLY (STAINLESS)
W11247220 W11247220 MICROWAVE DOOR ASSEMBLY (WHITE)
W10156812 W10156812 MICROWAVE DOOR INTERLOCK SPRING
WPW10156813 WPW10156813 MICROWAVE DOOR INTERLOCK SUPPORT, LOWER
WP8206419 WP8206419 MICROWAVE DOOR INTERLOCK SUPPORT, UPPER
W10138793 W10138793 MICROWAVE FUSE
W10208631A W10208631A MICROWAVE GREASE FILTER
8206562 8206562 MICROWAVE HIGH-VOLTAGE CAPACITOR
W11256462 W11256462 MICROWAVE HIGH-VOLTAGE DIODE
W10821385 W10821385 MICROWAVE INSTALLATION HARDWARE KIT
W10190018 W10190018 MICROWAVE INSTALLATION TEMPLATE
WPW10210878 WPW10210878 MICROWAVE LIGHT SOCKET
W10210871 W10210871 MICROWAVE LIGHT SOCKET
WPW10693025 WPW10693025 MICROWAVE MAGNETRON
W10163422 W10163422 MICROWAVE MAGNETRON THERMISTOR
W10832024 W10832024 MICROWAVE MAGNETRON THERMOSTAT
W11122643 W11122643 MICROWAVE MOUNTING NUT
W11025649 W11025649 MICROWAVE MOUNTING PLATE
W10422269 W10422269 MICROWAVE NOISE FILTER
W10708076 W10708076 MICROWAVE POWER CORD
WP8169704 WP8169704 MICROWAVE SCREW
W10342991 W10342991 MICROWAVE SIDE AIR INLET COVER
8206232A 8206232A MICROWAVE SURFACE LIGHT BULB, 40-WATT
8206382 8206382 MICROWAVE SURFACE LIGHT LENS
W10240330 W10240330 MICROWAVE SURFACE LIGHT LENS
W10904020 W10904020 MICROWAVE THERMISTOR BRACKET
W10269232 W10269232 MICROWAVE THERMOSTAT
W10642989 W10642989 MICROWAVE TURNTABLE MOTOR
W11245707 W11245707 MICROWAVE TURNTABLE MOTOR COUPLER
8184109 8184109 MICROWAVE TURNTABLE MOTOR SPACER
W11291538 W11291538 MICROWAVE TURNTABLE TRAY
W11252182 W11252182 MICROWAVE TURNTABLE TRAY SUPPORT
W10843943 W10843943 MICROWAVE VENT DAMPER
W11229580 W11229580 MICROWAVE VENT DAMPER COVER
W10845643 W10845643 MICROWAVE VENT GRILLE
W10562613 W10562613 MICROWAVE VENT LOUVER MOTOR CAM PLATE
W10210855 W10210855 MICROWAVE VENT MOTOR CAPACITOR
W10539840 W10539840 MICROWAVE WIRE HARNESS
W10810142 W10810142 MICROWAVE WIRE HARNESS RETAINER
W10845642 W10845642 MICROWAVE/HOOD GRILLE VENT
W11301790 W11301790 MISCELLANEOUS PARTS, HARNESS, MAGNETRON TO HIGH...
W11207442 W11207442 OUTER_WRAPPI
W10770968 W10770968 PLATE
W11178521 W11178521 RANGE NAMEPLATE
W10190020 W10190020 TEMPLATE, UPPER
W10836753 W10836753 TRANSFORMER
