Manufacturer
LG
Model Number
23LS7DCUK
Description
23ls7dc-uk
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
BAG [A] |
|
|
BAG [A] |
|
|
BASE ASSEMBLY [900] |
|
|
CABINET ASSEMBLY [300] |
|
|
CAPACITOR,AL,CHIP [C720] |
|
|
CAPACITOR,CERAMIC,AXIAL [C4000] |
|
|
CAPACITOR,CERAMIC,CHIP [C5003] |
|
|
CAPACITOR,CERAMIC,CHIP [C717] |
|
|
CARD [A] |
|
|
CARD [A] |
|
|
COVER ASSEMBLY [400] |
|
|
COVER [910] |
|
|
COVER [A] |
|
|
COVER [A] |
|
|
COVER [A] |
|
|
COVER,REAR [902] |
|
|
HAND INSERT PCB ASSEMBLY,SUB [510] |
|
|
HARNESS,SINGLE [A] |
|
|
HARNESS,SINGLE [A] |
|
|
HARNESS,SINGLE [LV1] |
|
|
KNOB [511] |
|
|
LCD,MODULE-TFT [200] |
|
|
LED,DIP [LED5000] |
|
|
LENS [501] |
|
|
MAIN TOTAL ASSEMBLY [540] |
|
|
PACKAGE ASSEMBLY [A] |
|
|
PACKING [A] |
|
|
PACKING [A] |
|
|
PACKING [A] |
|
|
PCB ASSEMBLY,SUB [500] |
|
|
PLATE ASSEMBLY [820] |
|
|
PLATE [830] |
|
|
POWER CORD [A] |
|
|
RECEIVER MODULE [PA5000] |
|
|
REMOTE CONTROLLER [A2] |
|
|
RESISTOR,METAL FILM [R4000] |
|
|
RESISTOR,METAL FILM [R4001] |
|
|
RESISTOR,METAL FILM [R4002] |
|
|
SMPS,AC/DC [530] |
|
|
SPEAKER,FULL RANGE [120] |
|
|
SUPPORTER ASSEMBLY [A] |
|
|
SWITCH,TACT [SW4000] |
