Model Image
Manufacturer

LG

Model Number

ARUM168DTE5

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
AAB73610307 AAB73610307 ACCUMULATOR
MAA62904506 MAA62904506 ACCUMULATOR
AAB73610304 AAB73610304 ACCUMULATOR ASSEMBLY
AAB73610308 AAB73610308 ACCUMULATOR ASSEMBLY
AAB73610348 AAB73610348 ACCUMULATOR ASSEMBLY
AAB73610356 AAB73610356 ACCUMULATOR ASSEMBLY
AAN75070507 AAN75070507 BASE ASSEMBLY,OUTDOOR
AAN75070502 AAN75070502 BASE ASSEMBLY,WELD(OUTDOOR)
MAZ64568901 MAZ64568901 BRACKET
MAZ64569001 MAZ64569001 BRACKET
ABQ75748012 ABQ75748012 CASE ASSEMBLY,CONTROL BOX
4H01930A 4H01930A CLAMP,SPRING
EAP65270715 EAP65270715 COIL MODULE,EXPANSION
EAP65270901 EAP65270901 COIL MODULE,SOLENOID
EAP65270902 EAP65270902 COIL MODULE,SOLENOID
EAP65270903 EAP65270903 COIL MODULE,SOLENOID
EAP65270904 EAP65270904 COIL MODULE,SOLENOID
EAP30616913 EAP30616913 COIL,EXPANSION
EAP63107117 EAP63107117 COIL,EXPANSION
TBZ37957101 TBZ37957101 COMPRESSOR SET,KOREA
ACG74565005 ACG74565005 CONDENSER ASSEMBLY,BENDING
EBR80820502 EBR80820502 CONTROL BOARD
EBR32221413 EBR32221413 CONTROL BOARD,CYCLE(ONBOARDING)
MCK40005905 MCK40005905 COVER
MCK40005015 MCK40005015 COVER
MCK40004912 MCK40004912 COVER
ACQ33787704 ACQ33787704 COVER ASSEMBLY
ACQ87960104 ACQ87960104 COVER ASSEMBLY,CONTROL(OUTDOOR)
ACQ87960121 ACQ87960121 COVER ASSEMBLY,CONTROL(OUTDOOR)
ACQ87691201 ACQ87691201 COVER ASSEMBLY,TOP(OUTDOOR)
ACQ87691221 ACQ87691221 COVER ASSEMBLY,TOP(OUTDOOR)
MCQ62569601 MCQ62569601 DAMPER,COMPRESSOR
MCQ70869701 MCQ70869701 DAMPER,RUBBER
MJX63992003 MJX63992003 EXPANSION BODY VALVE
ADP74093302 ADP74093302 FAN ASSEMBLY,PROPELLER
EAM63430905 EAM63430905 FILTER,AC LINE
EAF62630201 EAF62630201 FUSE,TIME DELAY
MDS42399720 MDS42399720 GASKET
MDX63411902 MDX63411902 GRILLE,INLET
EAD63326201 EAD63326201 HARNESS,MULTI
EAD62666216 EAD62666216 HARNESS,MULTI
EAD62666215 EAD62666215 HARNESS,MULTI
EAD63306518 EAD63306518 HARNESS,SINGLE
EAD63306516 EAD63306516 HARNESS,SINGLE
EAD62092202 EAD62092202 HARNESS,SINGLE
EAD63306517 EAD63306517 HARNESS,SINGLE
EAD63306507 EAD63306507 HARNESS,SINGLE
EAD63306504 EAD63306504 HARNESS,SINGLE
EAD63306514 EAD63306514 HARNESS,SINGLE
EAD63306513 EAD63306513 HARNESS,SINGLE
EAD63306503 EAD63306503 HARNESS,SINGLE
EAD62092260 EAD62092260 HARNESS,SINGLE
EAD62092271 EAD62092271 HARNESS,SINGLE
MED37293714 MED37293714 HEAT SINK
AEF74124508 AEF74124508 HEAT SINK ASSEMBLY
AEF76105001 AEF76105001 HEAT SINK ASSEMBLY
MEE61984929 MEE61984929 HEATER,SUMP
MEE61984928 MEE61984928 HEATER,SUMP
MFA62922902 MFA62922902 LEG
EAU43080021 EAU43080021 MOTOR ASSEMBLY,DC,OUTDOOR
AGL74852510 AGL74852510 PANEL ASSEMBLY,FRONT(OUTDOOR)
AGL74913401 AGL74913401 PANEL ASSEMBLY,SIDE
AGL74913301 AGL74913301 PANEL ASSEMBLY,SIDE
MGC63779002 MGC63779002 PANEL,FRONT
MGC63818902 MGC63818902 PANEL,UPPER
EBR83674713 EBR83674713 PCB ASSEMBLY,CYCLE(ONBOARDING)
EBR88279204 EBR88279204 PCB ASSEMBLY,FAN(ONBOARDING)
EBR88279006 EBR88279006 PCB ASSEMBLY,INV(ONBOARDING)
EBR79669909 EBR79669909 PCB ASSEMBLY,MAIN
EBR80100301 EBR80100301 PCB ASSEMBLY,SENSOR
EBR80820501 EBR80820501 PCB ASSEMBLY,SUB
MKW30000003 MKW30000003 PLUG,FUSIBLE
MKW30000006 MKW30000006 PLUG,FUSIBLE
EBD62165601 EBD62165601 SENSOR,PRESSURE
EBD60663823 EBD60663823 SENSOR,PRESSURE
AJR75462801 AJR75462801 SEPARATOR,OIL
MJX62792301 MJX62792301 SERVICE VALVE
MHN62782001 MHN62782001 SHROUD
AHV74029801 AHV74029801 SHROUD ASSEMBLY
6141A20010W 6141A20010W SOLENOID
EBE61083215 EBE61083215 SOLENOID
EBE61083214 EBE61083214 SOLENOID
EBE61083211 EBE61083211 SOLENOID
EBE60742004 EBE60742004 SOLENOID
EBE60661414 EBE60661414 SOLENOID
EBE61083212 EBE61083212 SOLENOID
EBE61621601 EBE61621601 SOLENOID
EBE61083201 EBE61083201 SOLENOID
EBE60661416 EBE60661416 SOLENOID
EBE60661415 EBE60661415 SOLENOID
EBE60661407 EBE60661407 SOLENOID
6141A20010U 6141A20010U SOLENOID
5220A90008T 5220A90008T SOLENOID VALVE
MDS65550303 MDS65550303 SOUND PROOF
MDS65550301 MDS65550301 SOUND PROOF
MJH63775701 MJH63775701 SUPPORTER
MJH63754102 MJH63754102 SUPPORTER
MJH63754004 MJH63754004 SUPPORTER
AJJ73799914 AJJ73799914 SUPPORTER ASSEMBLY
AJJ73639907 AJJ73639907 SUPPORTER ASSEMBLY
AJJ73639906 AJJ73639906 SUPPORTER ASSEMBLY
AJJ76559005 AJJ76559005 SUPPORTER ASSEMBLY
AJJ76559006 AJJ76559006 SUPPORTER ASSEMBLY
EBF40271415 EBF40271415 SWITCH,PRESSURE
EBF40271416 EBF40271416 SWITCH,PRESSURE
6640A30004H 6640A30004H TERMINAL BLOCK CONNECTOR
EBG61107408 EBG61107408 THERMISTOR ASSEMBLY,NTC
EBG61107310 EBG61107310 THERMISTOR ASSEMBLY,NTC
EBG61107412 EBG61107412 THERMISTOR ASSEMBLY,NTC
EBG61486302 EBG61486302 THERMISTOR ASSEMBLY,NTC
EBJ61631013 EBJ61631013 TRANSFORMER,LINEAR
AJR77226001 AJR77226001 TUBE ASSEMBLY
AJR75463502 AJR75463502 TUBE ASSEMBLY,CONNECTOR
AJR74984601 AJR74984601 TUBE ASSEMBLY,CONNECTOR
AJR75122501 AJR75122501 TUBE ASSEMBLY,CONNECTOR
AJR74984402 AJR74984402 TUBE ASSEMBLY,CONNECTOR
AJR77225701 AJR77225701 TUBE ASSEMBLY,CONNECTOR
AJR77225801 AJR77225801 TUBE ASSEMBLY,CONNECTOR
AJR75463515 AJR75463515 TUBE ASSEMBLY,CONNECTOR
AJR75462809 AJR75462809 TUBE ASSEMBLY,DISCHARGE(OUTDOOR)
AJR76163903 AJR76163903 TUBE ASSEMBLY,DISCHARGE(OUTDOOR)
AJR76163902 AJR76163902 TUBE ASSEMBLY,DISCHARGE(OUTDOOR)
AJR75563603 AJR75563603 TUBE ASSEMBLY,DISTRIBUTOR
AJR75563702 AJR75563702 TUBE ASSEMBLY,DISTRIBUTOR
AJR77244401 AJR77244401 TUBE ASSEMBLY,DISTRIBUTOR
AJR77244501 AJR77244501 TUBE ASSEMBLY,DISTRIBUTOR
AJR75544201 AJR75544201 TUBE ASSEMBLY,EXPANSION
AJR75462901 AJR75462901 TUBE ASSEMBLY,EXPANSION
AJR77224502 AJR77224502 TUBE ASSEMBLY,EXPANSION
AJR77224519 AJR77224519 TUBE ASSEMBLY,EXPANSION
AJR77189403 AJR77189403 TUBE ASSEMBLY,EXPANSION
AJR77189404 AJR77189404 TUBE ASSEMBLY,EXPANSION
AJR77223901 AJR77223901 TUBE ASSEMBLY,EXPANSION
AJR74984303 AJR74984303 TUBE ASSEMBLY,MANIFOLD(OUTDOOR)
AJR77225301 AJR77225301 TUBE ASSEMBLY,MANIFOLD(OUTDOOR)
AJR77225303 AJR77225303 TUBE ASSEMBLY,MANIFOLD(OUTDOOR)
AJR74983908 AJR74983908 TUBE ASSEMBLY,REVERSE
AJR30027707 AJR30027707 TUBE ASSEMBLY,REVERSE
AJR75463208 AJR75463208 TUBE ASSEMBLY,SUCTION(OUTDOOR)
AJR30001201 AJR30001201 TUBE ASSEMBLY,SUCTION(OUTDOOR)
AJR30001207 AJR30001207 TUBE ASSEMBLY,SUCTION(OUTDOOR)
AJU73472415 AJU73472415 VALVE ASSEMBLY
AJU73472403 AJU73472403 VALVE ASSEMBLY
AJU73472406 AJU73472406 VALVE ASSEMBLY
AJU73472405 AJU73472405 VALVE ASSEMBLY
MJX39414109 MJX39414109 VALVE,CHECK
MJX62771702 MJX62771702 VALVE,CHECK
MJX39414102 MJX39414102 VALVE,CHECK
MJX62751401 MJX62751401 VALVE,EXPANSION BODY
5220A20039A 5220A20039A VALVE,REVERSE
MJX62254101 MJX62254101 VALVE,SERVICE
MJX64331401 MJX64331401 VALVE,SERVICE
MJX65110301 MJX65110301 VALVE,SERVICE
MJX65117203 MJX65117203 VALVE,SERVICE
MJX65117202 MJX65117202 VALVE,SERVICE
MJX61537802 MJX61537802 VALVE,SOLENOID
5220A20012A 5220A20012A VALVE,SOLENOID
5220A90008Q 5220A90008Q VALVE,SOLENOID
MJX38529001 MJX38529001 VALVE,SOLENOID
5220A90008H 5220A90008H VALVE,SOLENOID
MJX61537801 MJX61537801 VALVE,SOLENOID
MJX61537805 MJX61537805 VALVE,SOLENOID
