Manufacturer
LG
Model Number
AVMC18SB
Description
A-vmc18sb
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
BARRIER ASSEMBLY,OUTDOOR |
|
|
BARRIER ASSEMBLY,OUTDOOR [447910] |
|
|
BASE ASSEMBLY,OUTDOOR |
|
|
BRACKET ASSEMBLY,MOTOR(OUTDOOR) |
|
|
BRACKET,MOTOR [349600] |
|
|
CAPACITOR,FILM,BOX [W0CZZ] |
|
|
CASE ASSEMBLY,CONTROL(OUTDOOR) [649950] |
|
|
COMPRESSOR [554160] |
|
|
CONDENSER ASSEMBLY,BENDING [554031] |
|
|
CONNECTOR,TERMINAL BLOCK [W6640] |
|
|
COVER |
|
|
COVER ASSEMBLY,CONTROL(OUTDOOR) |
|
|
COVER ASSEMBLY,CONTROL(OUTDOOR) [435511] |
|
|
COVER ASSEMBLY,TOP(OUTDOOR) |
|
|
COVER ASSEMBLY,TOP(OUTDOOR) [435512] |
|
|
DAMPER,COMPRESSOR [550140] |
|
|
DRAWING,ASSEMBLY [661400] |
|
|
FAN,PROPELLER [559010] |
|
|
GASKET [430960A] |
|
|
GRILLE,DISCHARGE |
|
|
GRILLE,DISCHARGE [435301] |
|
|
HARNESS,MULTI |
|
|
MOTOR ASSEMBLY,AC,OUTDOOR [546810] |
|
|
NIPPLE,DRAIN |
|
|
ORIFICE [349480] |
|
|
PANEL ASSEMBLY,FRONT(OUTDOOR) [437211] |
|
|
PANEL ASSEMBLY,REAR(OUTDOOR) |
|
|
PANEL ASSEMBLY,REAR(OUTDOOR) [437212] |
|
|
PANEL,FRONT |
|
|
PCB ASSEMBLY,MAIN [268711F] |
|
|
SUPPORTER ASSEMBLY |
|
|
THERMISTOR ASSEMBLY,NTC |
|
|
THERMISTOR ASSEMBLY,NTC [263230D] |
|
|
THERMISTOR,NTC [567480E] |
|
|
TRANSFORMER,REACTOR |
|
|
TRANSFORMER,REACTOR [261704] |
|
|
TUBE ASSEMBLY,CONDENSER(IN) |
|
|
TUBE ASSEMBLY,CONDENSER(OUT) [552113] |
|
|
VALVE,EXPANSION BODY |
|
|
VALVE,SERVICE [552203A] |
|
|
VALVE,SERVICE [552203A] |
|
|
VALVE,SERVICE [552203B] |
|
|
VALVE,SERVICE [552203B] |
