Model Image
Manufacturer

LG

Model Number

DLG7201WE

Description

7.3 Cu. Ft. Smart Wi-fi Enabled Gas Dryer With Sen

Interactive Exploded View
Exploded View

Parts List

Part Number Description
AAA75904801 AAA75904801 ACCESSORY ASSEMBLY
MAK62727101 MAK62727101 BAR,CONNECTOR
MAK63888501 MAK63888501 BAR,CONNECTOR
4400EL2001A 4400EL2001A BELT,POLY V
4400EL2001F 4400EL2001F BELT,POLY V
5835EL1002A 5835EL1002A BLOWER ASSEMBLY
4810EL1002A 4810EL1002A BRACKET
4810EL3001A 4810EL3001A BRACKET,BASE
4810EL3002A 4810EL3002A BRACKET,BASE
MAZ63869301 MAZ63869301 BRACKET,HINGE
MAZ61975501 MAZ61975501 BRACKET,HINGE
MAZ63869201 MAZ63869201 BRACKET,HINGE
MAZ66065301 MAZ66065301 BRACKET,MOTOR
ABJ73928239 ABJ73928239 CABINET ASSEMBLY
MBL67041501 MBL67041501 CAP,COVER
MBL65578901 MBL65578901 CAP,COVER
MBL65958102 MBL65958102 CAP,COVER
MBL65958101 MBL65958101 CAP,COVER
5006EL3001D 5006EL3001D CAP,DRIER
MBL62213306 MBL62213306 CAP,HOLE
MBL62213301 MBL62213301 CAP,HOLE
4860EL3001A 4860EL3001A CLAMP
4932EL4001A 4932EL4001A CONNECTOR (MECH),PIPE
6631EL3003B 6631EL3003B CONNECTOR ASSEMBLY
MCD62587102 MCD62587102 CONNECTOR,NOZZLE
ACQ86644201 ACQ86644201 COVER ASSEMBLY,CABINET
3550EL2004B 3550EL2004B COVER,FILTER
3550EL1005C 3550EL1005C COVER,GUIDE
3550EL2003B 3550EL2003B COVER,PROTECT
4W50100F 4W50100F CUSTOMIZED
ACV73430101 ACV73430101 DAMPER ASSEMBLY
MCR66471703 MCR66471703 DECOR,PANEL
ADC74129518 ADC74129518 DOOR ASSEMBLY
5209EL1001R 5209EL1001R DUCT ASSEMBLY
5209EL1001E 5209EL1001E DUCT ASSEMBLY
5209EL1002A 5209EL1002A DUCT ASSEMBLY
5209EL1006A 5209EL1006A DUCT ASSEMBLY
5231EL1001C 5231EL1001C FILTER ASSEMBLY,LINT
ADV74568801 ADV74568801 FRAME ASSEMBLY
3017EL1001A 3017EL1001A FUNNEL
MDS61982901 MDS61982901 GASKET
4975EL3001A 4975EL3001A GUIDE ASSEMBLY
4974EL1001A 4974EL1001A GUIDE,BURNER
4974EL1002B 4974EL1002B GUIDE,FILTER
MEB63034502 MEB63034502 HANDLE
AED73953301 AED73953301 HANDLE ASSEMBLY
EAD60946420 EAD60946420 HARNESS,MULTI
MEF62782101 MEF62782101 HINGE
MEF62782201 MEF62782201 HINGE
MEF62782001 MEF62782001 HINGE
AEH74256601 AEH74256601 HINGE ASSEMBLY
4930ER4003B 4930ER4003B HOLDER
4930ER4002A 4930ER4002A HOLDER
4930EL3004A 4930EL3004A HOLDER
AEJ33026601 AEJ33026601 HOLDER ASSEMBLY
AGM30061302 AGM30061302 HOUSING,BLOWER
5318EL3001A 5318EL3001A IGNITER
AEZ73913403 AEZ73913403 KNOB ASSEMBLY
AEZ73913404 AEZ73913404 KNOB ASSEMBLY
EAQ61400801 EAQ61400801 LAMP,LED
4778EL3001B 4778EL3001B LEG
4432EL1002A 4432EL1002A LIFTER
4027EL1001C 4027EL1001C LOCKER ASSEMBLY
MFG63878901 MFG63878901 LOCKER,BODY
MFG63098601 MFG63098601 LOCKER,HANDLE
4026EL3007C 4026EL3007C LOCKER,HOOK
MFG63098701 MFG63098701 LOCKER,HOOK
4681EL1008A 4681EL1008A MOTOR,UNCLASSIFIED
4948EL4001B 4948EL4001B ORIFICE-NATURAL GAS
AGL75452909 AGL75452909 PANEL ASSEMBLY,FRONT
MGC64406329 MGC64406329 PANEL,REAR
MGC64406319 MGC64406319 PANEL,REAR
383EEL9001G 383EEL9001G PARTS ASSEMBLY
383EEL3002R 383EEL3002R PARTS ASSEMBLY
EBR85069901 EBR85069901 PCB ASSEMBLY,DISPLAY
EBR80198612 EBR80198612 PCB ASSEMBLY,MAIN
5201EL3001A 5201EL3001A PIPE ASSEMBLY
5201EL2001A 5201EL2001A PIPE ASSEMBLY
AGU72925531 AGU72925531 PLATE ASSEMBLY,TOP
AGU72925524 AGU72925524 PLATE ASSEMBLY,TOP
3300EL4001B 3300EL4001B PLATE,UPPER
6411ER1005B 6411ER1005B POWER CORD ASSEMBLY
4561EL3002A 4561EL3002A PULLEY ASSEMBLY,MOTOR
4560EL3001A 4560EL3001A PULLEY,IDLE
3750EL0001C 3750EL0001C RACK
4581EL3001M 4581EL3001M ROLLER ASSEMBLY
4581EL2002L 4581EL2002L ROLLER ASSEMBLY
4000FD4191A 4000FD4191A SCREW
FAB32258901 FAB32258901 SCREW,CUSTOMIZED
1SZZEL2001A 1SZZEL2001A SCREW,CUSTOMIZED
1SZZEL4001B 1SZZEL4001B SCREW,CUSTOMIZED
1SZZEL3001A 1SZZEL3001A SCREW,DRAWING
FAB32139906 FAB32139906 SCREW,TAPPING
1TPL0303218 1TPL0303218 SCREW,TAPPING
1FTF0503507 1FTF0503507 SCREW,TAPTITE
4036EL3002A 4036EL3002A SEAL
4036EL3001A 4036EL3001A SEAL
6501EL3001A 6501EL3001A SENSOR ASSEMBLY
6500EL3001A 6500EL3001A SENSOR,HUMIDITY
3911EZ9131X 3911EZ9131X SIDE VENTING KIT
MHY63244303 MHY63244303 SPRING,COIL
MHY63244302 MHY63244302 SPRING,COIL
MHY63244301 MHY63244301 SPRING,COIL
4970EL4002C 4970EL4002C SPRING,DISTORTION
MJH64476101 MJH64476101 SUPPORTER,HINGE
MJH63096901 MJH63096901 SUPPORTER,HINGE
4980EL3001A 4980EL3001A SUPPORTER,HOLDER
EBF61496102 EBF61496102 SWITCH ASSEMBLY,DOOR
EBF61734701 EBF61734701 SWITCH,MICRO
AGM30045804 AGM30045804 THERMISTOR ASSEMBLY
6931EL3002M 6931EL3002M THERMOSTAT
1TTL0402418 1TTL0402418 TP SCREW+2 CUT 303,1003TMA-117
3045EL1005K 3045EL1005K TUB ASSEMBLY,DRUM
3045EL1002K 3045EL1002K TUB ASSEMBLY,DRUM
3045EL1005D 3045EL1005D TUB ASSEMBLY,DRUM
3044EL0002P 3044EL0002P TUB,DRUM(REAR)
3044EL0002C 3044EL0002C TUB,DRUM[BACK]
3300EL4001A 3300EL4001A UPPER PLATE CLIP
5221EL2002A 5221EL2002A VALVE ASSEMBLY,GAS
