Model Image
Manufacturer

LG

Model Number

DLGX4371W

Description

7.4 Cu. Ft. Ultra Large Capacity Turbosteam/gas Dr

Interactive Exploded View
Exploded View

Parts List

Part Number Description
AAA75232311 AAA75232311 ACCESSORY ASSEMBLY
MAG61843101 MAG61843101 BALANCE WEIGHT
4400EL2001A 4400EL2001A BELT,POLY V
4400EL2001F 4400EL2001F BELT,POLY-V
5835EL1002A 5835EL1002A BLOWER ASSEMBLY
4810EL1002A 4810EL1002A BRACKET
4810EL3009D 4810EL3009D BRACKET,BASE
4810EL3009A 4810EL3009A BRACKET,BASE
4810EL3001B 4810EL3001B BRACKET,BASE
MEJ62505602 MEJ62505602 BRACKET,BASE
4810EL3009C 4810EL3009C BRACKET,BASE
4810EL3002A 4810EL3002A BRACKET,BASE
MAZ64606102 MAZ64606102 BRACKET,FRAME
MAZ47156201 MAZ47156201 BRACKET,HINGE
MAZ66065301 MAZ66065301 BRACKET,MOTOR
ABJ34640605 ABJ34640605 CABINET ASSEMBLY
4860EL3001A 4860EL3001A CLAMP
4932EL4001A 4932EL4001A CONNECTOR (MECH),PIPE
6631EL3003B 6631EL3003B CONNECTOR ASSEMBLY
MCD63206801 MCD63206801 CONNECTOR,NOZZLE
MCD62587102 MCD62587102 CONNECTOR,NOZZLE
MCD63306801 MCD63306801 CONNECTOR,PIPE
ACQ52740901 ACQ52740901 COVER ASSEMBLY,CABINET
MCK66787901 MCK66787901 COVER,FILTER
MCK49049101 MCK49049101 COVER,GUIDE
MCK62423301 MCK62423301 COVER,SAFETY
4W50100F 4W50100F CUSTOMIZED
MCQ62786001 MCQ62786001 DAMPER
MCR65109903 MCR65109903 DECOR,GUARD
ADC74047201 ADC74047201 DOOR ASSEMBLY
5209EL1001R 5209EL1001R DUCT ASSEMBLY
5209EL1001L 5209EL1001L DUCT ASSEMBLY
5209EL1001E 5209EL1001E DUCT ASSEMBLY
5209EL1002C 5209EL1002C DUCT ASSEMBLY
5209EL1006A 5209EL1006A DUCT ASSEMBLY
ADQ56656403 ADQ56656403 FILTER ASSEMBLY,LINT
ADQ56656401 ADQ56656401 FILTER ASSEMBLY,LINT
ADV33609806 ADV33609806 FRAME ASSEMBLY
MDQ47196703 MDQ47196703 FRAME,DOOR(INNER)
MDQ63216401 MDQ63216401 FRAME,DOOR(OUTER)
3017EL1001A 3017EL1001A FUNNEL
MDS47263101 MDS47263101 GASKET
ADZ73410102 ADZ73410102 GENERATOR ASSEMBLY
ADZ73410101 ADZ73410101 GENERATOR ASSEMBLY
4975EL3001A 4975EL3001A GUIDE ASSEMBLY
4974EL1001A 4974EL1001A GUIDE,BURNER
MEA49050001 MEA49050001 GUIDE,FILTER
EAD60870422 EAD60870422 HARNESS,MULTI
EAD39301910 EAD39301910 HARNESS,MULTI
MEF47197001 MEF47197001 HINGE
AEJ33026401 AEJ33026401 HOLDER
4930EL2004D 4930EL2004D HOLDER
AEJ33026601 AEJ33026601 HOLDER ASSEMBLY
5215FD3715V 5215FD3715V HOSE,INLET
MEJ62404702 MEJ62404702 HOSE,INLET
5215FD3715W 5215FD3715W HOSE,INLET
AGM30061302 AGM30061302 HOUSING,BLOWER
5318EL3001A 5318EL3001A IGNITER
4941ER3005A 4941ER3005A KNOB ASSEMBLY
4941ER3005D 4941ER3005D KNOB ASSEMBLY
EAQ61400801 EAQ61400801 LAMP,LED
4778EL3001B 4778EL3001B LEG
4432EL1002A 4432EL1002A LIFTER
4027EL1001B 4027EL1001B LOCKER ASSEMBLY
4026EL3007B 4026EL3007B LOCKER,HOOK
AFN77913542 AFN77913542 MANUAL ASSEMBLY,OWNERS
4681EL1008A 4681EL1008A MOTOR,UNCLASSIFIED
4948EL4001B 4948EL4001B ORIFICE-NATURAL GAS
AGL55862071 AGL55862071 PANEL ASSEMBLY,CONTROL
383EEL9001D 383EEL9001D PARTS ASSEMBLY
383EEL3002R 383EEL3002R PARTS ASSEMBLY
383EEL9001G 383EEL9001G PARTS ASSEMBLY
EBR83191601 EBR83191601 PCB ASSEMBLY,DISPLAY
EBR83258902 EBR83258902 PCB ASSEMBLY,MAIN
5201EL3001A 5201EL3001A PIPE ASSEMBLY
5201EL2001A 5201EL2001A PIPE ASSEMBLY
AGU30071288 AGU30071288 PLATE ASSEMBLY,TOP
3300EL2001A 3300EL2001A PLATE,UPPER
6411ER1005B 6411ER1005B POWER CORD ASSEMBLY
AGM34418433 AGM34418433 POWER CORD ASSEMBLY
4561EL3002A 4561EL3002A PULLEY ASSEMBLY,MOTOR
4560EL3001A 4560EL3001A PULLEY,IDLE
3750EL1001A 3750EL1001A RACK
4581EL3001M 4581EL3001M ROLLER ASSEMBLY
4581EL2002L 4581EL2002L ROLLER ASSEMBLY
1MTC0402632 1MTC0402632 SCREW
1SZZEL2001A 1SZZEL2001A SCREW,CUSTOMIZED
1SZZEL3001A 1SZZEL3001A SCREW,DRAWING
FAB32139906 FAB32139906 SCREW,TAPPING
1TPL0303218 1TPL0303218 SCREW,TAPPING
1FTF0503507 1FTF0503507 SCREW,TAPTITE
1APF0402608 1APF0402608 SCREW,TAPTITE
4036EL3002A 4036EL3002A SEAL
4036EL3001A 4036EL3001A SEAL
6500EL3001A 6500EL3001A SENSOR
6501EL3001A 6501EL3001A SENSOR ASSEMBLY
3911EZ9131X 3911EZ9131X SIDE VENTING KIT
4970EL4002C 4970EL4002C SPRING,DISTORTION
4980EL3001A 4980EL3001A SUPPORTER,HOLDER
EBF61496102 EBF61496102 SWITCH ASSEMBLY,DOOR
EBF61734701 EBF61734701 SWITCH,MICRO
AGM30045804 AGM30045804 THERMISTOR ASSEMBLY
6931EL3002M 6931EL3002M THERMOSTAT
5215FD3715M 5215FD3715M TOP LOAD INLET HOSE (COLD)
3045EL1002P 3045EL1002P TUB ASSEMBLY,DRUM
3045EL1002K 3045EL1002K TUB ASSEMBLY,DRUM
AJQ75298102 AJQ75298102 TUB ASSEMBLY,DRUM
AJQ73594004 AJQ73594004 TUB ASSEMBLY,DRUM
AJQ73594008 AJQ73594008 TUB ASSEMBLY,DRUM
3044EL0002N 3044EL0002N TUB,DRUM(REAR)
3044EL0002T 3044EL0002T TUB,DRUM(REAR)
5221EL2002A 5221EL2002A VALVE ASSEMBLY,GAS
AJU73432602 AJU73432602 VALVE ASSEMBLY,INLET
