Manufacturer

LG

Model Number

GRK303DS

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
4680JB1036N 4680JB1036N AC MOTOR [404B]
4791JA1036G 4791JA1036G BARRIER ASSEMBLY,INSULATION [245A]
3103JA0010C 3103JA0010C BASE ASSEMBLY,COMPRESSOR [315A]
5004JA0007A 5004JA0007A BASKET,DOOR [241A]
5004JA0006A 5004JA0006A BASKET,DOOR [241B]
4810JA3007B 4810JA3007B BRACKET,MOTOR [405A]
4810JA2139A 4810JA2139A BRACKET,VALVE [319D]
5075JA1030E 5075JA1030E BUCKET ASSEMBLY,SIDE DISH [251A]
5075JA1028D 5075JA1028D BUCKET ASSEMBLY,SIDE DISH [252A]
5075JA1030D 5075JA1030D BUCKET ASSEMBLY,SIDE DISH [253A]
5075JA1027D 5075JA1027D BUCKET ASSEMBLY,SIDE DISH [254A]
5074JA1053B 5074JA1053B BUCKET,SIDE DISH [252B]
5074JA1057B 5074JA1057B BUCKET,SIDE DISH [253B]
5074JA1052B 5074JA1052B BUCKET,SIDE DISH [254B]
5020JA2050A 5020JA2050A BUTTON,DECOR [279D]
5020JA2051A 5020JA2051A BUTTON,LINK [279E]
5006JA3017G 5006JA3017G CAP,SCREW [109B]
0CZZJB2010H 0CZZJB2010H CAPACITOR,ELECTRIC APPLIANCE FILM,RADIAL [410G]
J513-00012P J513-00012P CAPACITOR,ELECTRIC APPLIANCE FILM,RADIAL [410H]
3110JA1020B 3110JA1020B CASE,PCB [501K]
2521C-A62CD 2521C-A62CD COMPRESSOR,SET ASSEMBLY [307A]
5403JA1044A 5403JA1044A CONDENSER ASSEMBLY,WIRE [323B]
6615JB2005D 6615JB2005D CONTROLLER ASSEMBLY [401A]
6615JB2005A 6615JB2005A CONTROLLER ASSEMBLY [401B]
3551JA1070D 3551JA1070D COVER ASSEMBLY,BUCKET [252C]
3551JA1039A 3551JA1039A COVER ASSEMBLY,MACHINERY(REAR) [304A]
3550JA2143A 3550JA2143A COVER,DEODORIZER [604G]
3550JA1251D 3550JA1251D COVER,HINGE [281A]
3550JA0042E 3550JA0042E COVER,LOWER [103C]
3550JA1399C 3550JA1399C COVER,PCB [501F]
3550JA2035D 3550JA2035D COVER,SENSOR [610E]
5040JA3063A 5040JA3063A DAMPER [327B]
5040JA3071A 5040JA3071A DAMPER,COMPRESSOR [312A]
J756-00008A J756-00008A DAMPER,MOTOR SUPPORT [405C]
5072JA3003F 5072JA3003F DAMPER,NOISE [316A]
4J03020A 4J03020A DAMPER,PIPE [328A]
3806JA2140A 3806JA2140A DECOR,COVER DISPLAY [279C]
4756JA3001D 4756JA3001D DEODORIZER [604E]
ADC30624601 ADC30624601 DOOR ASSEMBLY,FREEZE ROOM [140A]
3581JA0052P 3581JA0052P DOOR ASSEMBLY,FREEZER [200A]
3581JA1055W 3581JA1055W DOOR ASSEMBLY,SEMI REFRIGERATOR [200B]
3581JA1056W 3581JA1056W DOOR ASSEMBLY,SEMI REFRIGERATOR [200C]
5433JA0138J 5433JA0138J DOOR FOAM ASSEMBLY,FREEZER [201A]
5433JA1068V 5433JA1068V DOOR FOAM ASSEMBLY,REFRIGERATOR [201B]
5433JA1069V 5433JA1069V DOOR FOAM ASSEMBLY,REFRIGERATOR [201C]
6877JB2163G 6877JB2163G DRAWING,ASSEMBLY [309B]
5851JA2002T 5851JA2002T DRIER ASSEMBLY [317A]
5421JA0045C 5421JA0045C EVAPORATOR ASSEMBLY [301A]
5421JA0027E 5421JA0027E EVAPORATOR ASSEMBLY [301B]
5901JA1014A 5901JA1014A FAN ASSEMBLY [329A]
5901JA1007A 5901JA1007A FAN ASSEMBLY [329B]
J753-00011A J753-00011A FAN ASSEMBLY [329C]
3211JA1074B 3211JA1074B FRAME ASSEMBLY,DISPLAY [279A]
3210JD1031B 3210JD1031B FRAME,DISPLAY [279B]
4987JA1024Y 4987JA1024Y GASKET ASSEMBLY,DOOR [203A]
4987JA1024L 4987JA1024L GASKET ASSEMBLY,DOOR [203B]
ADX72910303 ADX72910303 GASKET ASSEMBLY,DOOR [203C]
3531JA1045G 3531JA1045G GRILLE ASSEMBLY,FAN [332A]
3531JA1021C 3531JA1021C GRILLE ASSEMBLY,FAN [332A]
3531JA1022B 3531JA1022B GRILLE ASSEMBLY,FAN [332B]
4974JA1036B 4974JA1036B GUIDE,FAN [319C]
3651JA1007E 3651JA1007E HANDLE ASSEMBLY,FREEZER [212A]
3651JA1008E 3651JA1008E HANDLE ASSEMBLY,REFRIGERATOR [244A]
3650JA2108H 3650JA2108H HANDLE,DECOR [212B]
3650JA2109H 3650JA2109H HANDLE,DECOR [212C]
3650JA2110Q 3650JA2110Q HANDLE,DECOR [244B]
MEB62055503 MEB62055503 HANDLE,REAR [103A]
3650JA2061X 3650JA2061X HANDLE,REAR [103B]
5300JB1121D 5300JB1121D HEATER,SHEATH [418A]
5300JB1085D 5300JB1085D HEATER,SHEATH [418B]
4775JA3021A 4775JA3021A HINGE ASSEMBLY,CENTER [282B]
4775JA2008D 4775JA2008D HINGE ASSEMBLY,UPPER [281B]
AFC30700602 AFC30700602 LEG ASSEMBLY,FRAME [104A]
AFC30700601 AFC30700601 LEG ASSEMBLY,FRAME [104A]
4778JA2016D 4778JA2016D LEG,ADJUST [106A]
4680JB1036H 4680JB1036H MOTOR,AC [404A]
3846JD1007B 3846JD1007B NAME PLATE [239A]
6750C-0004S 6750C-0004S OVERLOAD PROTECT [309A]
6871JB1400C 6871JB1400C PCB ASSEMBLY,DISPLAY [501A]
6871JB1129Q 6871JB1129Q PCB ASSEMBLY,MAIN [500A]
4J04238A 4J04238A PIN,COMMON [315C]
3446JA2048F 3446JA2048F PLATE,CENTER [184C]
6411JB1011B 6411JB1011B POWER CORD ASSEMBLY [411A]
5219JA1004D 5219JA1004D RAIL ASSEMBLY,TV [248A]
5219JA1004E 5219JA1004E RAIL ASSEMBLY,TV [248B]
AHJ30124501 AHJ30124501 ROLLER ASSEMBLY [160C]
3J02312A 3J02312A ROLLER [315B]
4J00415D 4J00415D SCREW,CUSTOMIZED [W1SZ]
5026JA0015B 5026JA0015B SHELF,FREEZER [149C]
4999JA1017B 4999JA1017B SHROUD ASSEMBLY,FREEZER [330B]
4998JA1013A 4998JA1013A SHROUD,FREEZER [331D]
4J03277A 4J03277A STOPPER,COMPRESSOR [314A]
6600JB1005D 6600JB1005D SWITCH,PUSH BUTTON [406B]
6748C-0002C 6748C-0002C THERMISTOR ASSEMBLY,PTC [308A]
3391JA2027A 3391JA2027A TRAY ASSEMBLY,DRAIN [108A]
AJP30624801 AJP30624801 TRAY ASSEMBLY,DRAWER [136C]
3390JA0008B 3390JA0008B TRAY,DRIP [319A]
5251JA3003E 5251JA3003E TUBE ASSEMBLY,DRAIN [105A]
5251JA2006A 5251JA2006A TUBE ASSEMBLY,DRAIN [105B]
5221JA3002C 5221JA3002C VALVE ASSEMBLY,CHECK [619B]
5221JA1008A 5221JA1008A VALVE ASSEMBLY,PIPE [619A]
