Model Image
Manufacturer

LG

Model Number

LMVM1945SB

Description

Lmvm1945sb

Interactive Exploded View

Parts List

Part Number Description
4760W1A013A 4760W1A013A BAFFLE [1011]
3890W3Y874K 3890W3Y874K BOX [01-MAY]
4810W1A074A 4810W1A074A BRACKET,CONTROL PANEL [2008]
4810W1A151A 4810W1A151A BRACKET,IDLE [6010]
4810W1A149A 4810W1A149A BRACKET,MOUNT
4811W1A008B 4811W1A008B BRACKET,MOUNT [3029]
5020W1A155B 5020W1A155B BUTTON [2007]
0CZZW1M001C 0CZZW1M001C CAPACITOR,FILM,BOX [5000]
3B72440A 3B72440A CAPACITOR,FILM,BOX [5000]
3840W1T008B 3840W1T008B CARD,TECHNICAL [MBM2]
4922W5A060A 4922W5A060A CARD,TEMPLATE
4922W1A029A 4922W1A029A CARD,TEMPLATE [MBM4]
3112W0F013G 3112W0F013G CASE,FLAT [3001]
4051W3A001A 4051W3A001A CONNECTOR ASSEMBLY
4051W3A001C 4051W3A001C CONNECTOR ASSEMBLY [3054]
4781W1M333B 4781W1M333B CONTROLLER ASSEMBLY,KEYPAD [2004]
ACM30102502 ACM30102502 CONTROLLER ASSEMBLY,KEYPAD [2004]
3552W0A001B 3552W0A001B COVER,CHOKE [1004]
3550W2L001A 3550W2L001A COVER,LAMP
3550W1A171A 3550W1A171A COVER,LAMP [5045]
3550W3A084A 3550W3A084A COVER,POWER CORD [3031]
3550W1A169A 3550W1A169A COVER,STIRRER FAN [5044]
4900W1A001A 4900W1A001A DAMPER
4900W1A001B 4900W1A001B DAMPER [6011]
3806W1A077B 3806W1A077B DECOR,DOOR [1015]
3581W0A124F 3581W0A124F DOOR ASSEMBLY [1005]
5208W0A009A 5208W0A009A DUCT [5006]
5901W1A002G 5901W1A002G FAN ASSEMBLY [5024]
5900W1A004A 5900W1A004A FAN [5057]
EAM35001801 EAM35001801 FILTER,AC LINE [5041]
5230W1A003A 5230W1A003A FILTER,CHARCOAL [5037]
5230W2A004A 5230W2A004A FILTER,GREASE
3213W0A003D 3213W0A003D FRAME ASSEMBLY,DOOR [1000]
3B74133J 3B74133J FUSE,TIME DELAY
3B74133Q 3B74133Q FUSE,TIME DELAY [5001]
3B74133C 3B74133C FUSE,TIME DELAY [5001]
3530W0A028B 3530W0A028B GRILLE,VENT
4974W1A021A 4974W1A021A GUIDE,AIR [3007]
4974W0A007A 4974W0A007A GUIDE,AIR [5049]
4974W1A020A 4974W1A020A GUIDE,AIR [5052]
4974W1A019A 4974W1A019A GUIDE,SUCTION [5003]
3651W1A009B 3651W1A009B HANDLE ASSEMBLY
6877W1A453H 6877W1A453H HARNESS,SINGLE [2041]
6877W1A453G 6877W1A453G HARNESS,SINGLE [2042]
6877W1A450D 6877W1A450D HARNESS,SINGLE [5014]
6877W1A452A 6877W1A452A HARNESS,SINGLE [5019]
6631W3A003S 6631W3A003S HARNESS,SINGLE [5026]
3B72342U 3B72342U HARNESS,SINGLE [5032]
6850W1A001A 6850W1A001A HARNESS,SINGLE [5033]
6877W2S002F 6877W2S002F HARNESS,SINGLE [5132]
6877W1A453E 6877W1A453E HARNESS,SINGLE [5133]
6877W1A453F 6877W1A453F HARNESS,SINGLE [5134]
4931W1A011E 4931W1A011E HOLDER ASSEMBLY
4931W1A011D 4931W1A011D HOLDER ASSEMBLY [5056]
3501W1A036B 3501W1A036B HOLDER ASSEMBLY,LOCKER [4001]
3501W1A019J 3501W1A019J HOLDER ASSEMBLY,LOCKER [4001]
4930W1A069A 4930W1A069A HOLDER,COOK AUXILIARY [3036]
3500W1A028B 3500W1A028B HOLDER,LOCKER
3500W1A028A 3500W1A028A HOLDER,LOCKER [4000]
2B72771J 2B72771J KIT ASSEMBLY
3861W1A043C 3861W1A043C KIT ASSEMBLY [6009]
3850W1D097A 3850W1D097A LABEL,COOKING GUIDE [MEZ1]
6912A40002D 6912A40002D LAMP,HALOGEN
3501W1A044B 3501W1A044B LEVER [4004]
4026W2A015A 4026W2A015A LOCKER [1006]
6324W1A002C 6324W1A002C MAGNETRON
3828W5U0448 3828W5U0448 MANUAL,INSTALLATION
3828W5A3267 3828W5A3267 MANUAL,OWNERS
3506W0A001F 3506W0A001F MEMBRANE [2000]
6549W1S013H 6549W1S013H MOTOR, AC SYNCHRONOUS [3009]
6549W1S002J 6549W1S002J MOTOR, AC SYNCHRONOUS [5069]
6549W1V011A 6549W1V011A MOTOR, AC VENTILATION [3027]
6549W1F001W 6549W1F001W MOTOR,AC FAN [5012]
3720W0C118B 3720W0C118B PANEL,CONTROL [2002]
3720W0D302F 3720W0D302F PANEL,DOOR [1003]
6871W1S019A 6871W1S019A PCB ASSEMBLY,SUB
6871W1S209A 6871W1S209A PCB ASSEMBLY,SUB [2006]
6871W1S210A 6871W1S210A PCB ASSEMBLY,SUB [2009]
3300W0A030A 3300W0A030A PLATE ASSEMBLY [6008]
4960W1A008B 4960W1A008B PLATE [3010]
3303W1A059G 3303W1A059G PLATE,BASE [6000]
3300W1B001A 3300W1B001A PLATE,BOTTOM [5035]
3300W0A030C 3300W0A030C PLATE,MOUNT
6411W1A014N 6411W1A014N POWER CORD ASSEMBLY [5010]
6411W2A002E 6411W2A002E POWER CORD ASSEMBLY [5010]
3034W2A002B 3034W2A002B REFLECTOR
3034W2A003B 3034W2A003B REFLECTOR [3032]
3034W1A004A 3034W1A004A REFLECTOR [3072]
4351W1A001D 4351W1A001D RING ASSEMBLY
4B70188C 4B70188C SCREW,CUSTOMIZED [W102]
1TTL0402418 1TTL0402418 SCREW,TAPPING [W105]
1TTL0402818 1TTL0402818 SCREW,TAPPING [W109]
1TPL0402618 1TPL0402618 SCREW,TAPPING [W130]
1TPL0302418 1TPL0302418 SCREW,TAPPING [W136]
1TTL0402816 1TTL0402816 SCREW,TAPPING [W142]
1TTL0402618 1TTL0402618 SCREW,TAPPING [W144]
1TTL0403418 1TTL0403418 SCREW,TAPPING [W146]
1TTL0402622 1TTL0402622 SCREW,TAPPING [W149]
1TPL0302618 1TPL0302618 SCREW,TAPPING [W150]
1TTG0402422 1TTG0402422 SCREW,TAPTITE [W101]
6501W1A004A 6501W1A004A SENSOR ASSEMBLY [5011]
5026W1A052B 5026W1A052B SHELF [3018]
4970WRA001G 4970WRA001G SPRING [1007]
3B73362F 3B73362F SWITCH,MICRO [4002]
6600W1K001C 6600W1K001C SWITCH,MICRO [4003]
3B73361E 3B73361E SWITCH,MICRO [4003]
3536W1A006D 3536W1A006D TAPE,SEALING [1002]
3536WRA001T 3536WRA001T TAPE,SEALING [1002]
3B72543Q 3B72543Q THERMOSTAT
6930W1A003J 6930W1A003J THERMOSTAT
6930WRT003C 6930WRT003C THERMOSTAT
3390W1A023D 3390W1A023D TRAY ASSEMBLY
3390W0A001B 3390W0A001B TRAY,GLASS
5889W1A007B 5889W1A007B TURNTABLE ASSEMBLY [3008]
4890W1A030Q 4890W1A030Q WINDOW,GLASS [1008]
