Model Image
Manufacturer

LG

Model Number

LRE3061ST

Description

6.3 Cu. Ft. Electric Convection Range

Interactive Exploded View

Parts List

Part Number Description
AAA74970602 AAA74970602 ACCESSORY ASSEMBLY
AAA77169701 AAA77169701 ACCESSORY ASSEMBLY
AAA74970601 AAA74970601 ACCESSORY ASSEMBLY
AAA77169702 AAA77169702 ACCESSORY ASSEMBLY
AGM73551662 AGM73551662 AGM73551662
FAK30249601 FAK30249601 ANCHOR,CUSTOMIZED
3B72559A 3B72559A ANTI-C FAN
MAK61842901 MAK61842901 BAR
MAL62324001 MAL62324001 BARRIER
MAZ62210801 MAZ62210801 BARRIER
MAL62344203 MAL62344203 BARRIER
MAZ63478602 MAZ63478602 BRACKET
MAZ63310801 MAZ63310801 BRACKET,HEATER
MAZ63488301 MAZ63488301 BRACKET,HEATER
MAZ63491301 MAZ63491301 BRACKET,HEATER
MAZ63249701 MAZ63249701 BRACKET,HINGE
MAZ64590502 MAZ64590502 BRACKET,IDLE
MAZ61859001 MAZ61859001 BRACKET,IDLE
4810W3G135A 4810W3G135A BRACKET,IDLE
4810W1N060B 4810W1N060B BRACKET,MOTOR
MAZ63250601 MAZ63250601 BRACKET,MOUNT
MAZ61672102 MAZ61672102 BRACKET,MOUNT
MAZ61672103 MAZ61672103 BRACKET,MOUNT
MAZ60113203 MAZ60113203 BRACKET,MOUNT
MAZ63250901 MAZ63250901 BRACKET,MOUNT
4810W1A180A 4810W1A180A BRACKET,[MAGNETRON]
EAG32629301 EAG32629301 CONNECTOR,TERMINAL BLOCK
EAG32629306 EAG32629306 CONNECTOR,TERMINAL BLOCK
ACQ83872102 ACQ83872102 COVER ASSEMBLY,POISE
MCK66822314 MCK66822314 COVER,HEATER
MCK66838104 MCK66838104 COVER,INNER
MCK66822403 MCK66822403 COVER,POWER CORD
MCK66822702 MCK66822702 COVER,REAR
MCK66822701 MCK66822701 COVER,REAR
MCK66822601 MCK66822601 COVER,REAR
MCK66822801 MCK66822801 COVER,REAR
MCR32112501 MCR32112501 DECOR,DOOR
ADG73329501 ADG73329501 DRAWER ASSEMBLY
MDG62162801 MDG62162801 FAN,CONVECTION
4778W1N001B 4778W1N001B FOOT
ADV74166308 ADV74166308 FRAME ASSEMBLY,DOOR
ADV74166302 ADV74166302 FRAME ASSEMBLY,DOOR
MDQ63019801 MDQ63019801 FRAME,DOOR
MEB62494913 MEB62494913 HANDLE,DOOR
EAD62349801 EAD62349801 HARNESS,SINGLE
EAD61076101 EAD61076101 HARNESS,SINGLE
EAD62349811 EAD62349811 HARNESS,SINGLE
EAD34822916 EAD34822916 HARNESS,SINGLE
EAD61850402 EAD61850402 HARNESS,SINGLE
EAD34822910 EAD34822910 HARNESS,SINGLE
EAD61850512 EAD61850512 HARNESS,SINGLE
6877W1N024F 6877W1N024F HARNESS,SINGLE
EAD60833506 EAD60833506 HARNESS,SINGLE
EAD61850411 EAD61850411 HARNESS,SINGLE
EAD61850521 EAD61850521 HARNESS,SINGLE
AEG33897006 AEG33897006 HEATER ASSEMBLY
AEG33897003 AEG33897003 HEATER ASSEMBLY
MEE62385201 MEE62385201 HEATER,RADIATION
MEE62385001 MEE62385001 HEATER,RADIATION
MEE62385101 MEE62385101 HEATER,RADIATION
MEE62306504 MEE62306504 HEATER,SHEATH
MEE61925405 MEE61925405 HEATER,SHEATH
AEH72957502 AEH72957502 HINGE ASSEMBLY
MEV65052201 MEV65052201 INSULATOR
MEV63876302 MEV63876302 INSULATOR
MEV63876201 MEV63876201 INSULATOR
AEV72989602 AEV72989602 INSULATOR ASSEMBLY
AEV72989601 AEV72989601 INSULATOR ASSEMBLY
6913W1N002C 6913W1N002C LAMP,INCANDESCENT
4B72510F 4B72510F LUG
EAU61865302 EAU61865302 MOTOR,AC FAN
1NHB0500032 1NHB0500032 NUT,HEXAGON
MFZ63174202 MFZ63174202 PACKING,GASKET
MFZ63174201 MFZ63174201 PACKING,GASKET
3920W1N014A 3920W1N014A PACKING,MISC
3920W1N013A 3920W1N013A PACKING,SEAL
MGC62641501 MGC62641501 PANEL,DRAWER
MGC62640802 MGC62640802 PANEL,REAR
MGC62640801 MGC62640801 PANEL,REAR
MGC62644005 MGC62644005 PANEL,SIDE
AGM73551660 AGM73551660 PARTS ASSEMBLY
383EW0N001Z 383EW0N001Z PARTS ASSEMBLY
AGM73551661 AGM73551661 PARTS ASSEMBLY
EBR74164810 EBR74164810 PCB ASSEMBLY
EBR64624906 EBR64624906 PCB ASSEMBLY,DISPLAY
EBR77562706 EBR77562706 PCB ASSEMBLY,MAIN
EBR76332902 EBR76332902 PCB ASSEMBLY,SUB
AGU73969710 AGU73969710 PLATE ASSEMBLY
3302W1N001F 3302W1N001F PLATE,BASE
MGJ63105901 MGJ63105901 PLATE,FRONT
3300W1N003K 3300W1N003K PLATE,SHIELD
4B73725E 4B73725E RING
1ATF0502610 1ATF0502610 SCREW TAP TITE(B),TRUSS HEAD
1SZZW1N003A 1SZZW1N003A SCREW,CUSTOMIZED
1SZZW1E002C 1SZZW1E002C SCREW,CUSTOMIZED
FAB31821701 FAB31821701 SCREW,CUSTOMIZED
1SZZW5N001E 1SZZW5N001E SCREW,CUSTOMZIED
1SZZW1N006A 1SZZW1N006A SCREW,DRAWING
1SZZW5N001A 1SZZW5N001A SCREW,DRAWING
1SZZW5N001C 1SZZW5N001C SCREW,DRAWING
4000W4A001E 4000W4A001E SCREW,DRAWING
MHL63411403 MHL63411403 SHELF
MHS62022201 MHS62022201 SLIDER
MHS62022301 MHS62022301 SLIDER
MJH37701305 MJH37701305 SUPPORTER
MJH62535808 MJH62535808 SUPPORTER
4980W1N013A 4980W1N013A SUPPORTER
4980W1N014A 4980W1N014A SUPPORTER
MJH62535803 MJH62535803 SUPPORTER
MJH62535708 MJH62535708 SUPPORTER
MJH62758301 MJH62758301 SUPPORTER,PCB
EBF60663403 EBF60663403 SWITCH,TACT
1TTL0402418 1TTL0402418 TAPPING SCREW + 2 CUT 306 MA-1
EBG61305801 EBG61305801 THERMISTOR,PTC
6930W1A003X 6930W1A003X THERMOSTAT
1TTL0402618 1TTL0402618 TP SCREW + 2 CUT D4 L10 MA-117
AJV73009301 AJV73009301 VENT ASSEMBLY
1WSD0500032 1WSD0500032 WASHER,COMMON
1WSD0500075 1WSD0500075 WASHER,COMMON
1WZZ81N001A 1WZZ81N001A WASHER,CUSTOMIZED
1WZZW3Z003B 1WZZW3Z003B WASHER,CUSTOMIZED
4890W1N005X 4890W1N005X WINDOW,GLASS
4890W1N005A 4890W1N005A WINDOW,GLASS
