Model Image
Manufacturer

LG

Model Number

LRSPC2331NI

Description

Side-by-side Refrigerator

Interactive Exploded View
Exploded View

Parts List

Part Number Description
4770JA3001A 4770JA3001A BAND (MECH)
4770JA3001B 4770JA3001B BAND (MECH)
5075JA1007A 5075JA1007A BANK
5075JA1029Y 5075JA1029Y BANK ASSY,ICE
5004JD1126G 5004JD1126G BASKET,DOOR
5004JD1126E 5004JD1126E BASKET,DOOR
5004JD1126D 5004JD1126D BASKET,DOOR
5004JD1126A 5004JD1126A BASKET,DOOR
5004JD1101E 5004JD1101E BASKET,DOOR
5004JD1126C 5004JD1126C BASKET,DOOR
3890JC2836D 3890JC2836D BOX,GRAPHIC
4811JA2009A 4811JA2009A BRACKET ASSEMBLY,MOTOR
4810JA3059A 4810JA3059A BRACKET,COVER
4810JA1015A 4810JA1015A BRACKET,ICE MAKER
5075JA1029C 5075JA1029C BUCKET ASSEMBLY,ICE
5075JA1029F 5075JA1029F BUCKET ASSEMBLY,ICE
3807JA3006P 3807JA3006P BUTTON ASSEMBLY
5040JA2008D 5040JA2008D BUTTON,LEVER
5007JA3007C 5007JA3007C CAP ASSEMBLY,HEAD
ABN75058701 ABN75058701 CAP ASSY,HEAD
5078JA1033B 5078JA1033B CAP DECO, F (BOTTOM)
5078JA1033A 5078JA1033A CAP DECO, F (TOP)
5078JA1034B 5078JA1034B CAP DECO,R
5078JA1034A 5078JA1034A CAP DECO,R
J513-00012Z J513-00012Z CAPACITOR,DRAWING
0CZZJB2010G 0CZZJB2010G CAPACITOR,FILM,BOX
3111JA2007B 3111JA2007B CASE ASSY
3110JA1010A 3110JA1010A CASE,PWB
3103JA1014B 3103JA1014B COMP BASE ASSY
5403JA1003A 5403JA1003A CONDENSER ASSY,WIRE
4932JA3009A 4932JA3009A CONNECTOR (MECH),TUBE
4932JA3002A 4932JA3002A CONNECTOR (MECH),TUBE
4932JA3009B 4932JA3009B CONNECTOR (MECH),TUBE
MCD61866805 MCD61866805 CONNECTOR,TUBE
4995JA1021R 4995JA1021R CONTROL BOX ASSEMBLY,R
4994JD1036F 4994JD1036F CONTROL BOX,R
6615JB2002R 6615JB2002R CONTROLLER ASSEMBLY
3550JA2067A 3550JA2067A COVER
3551JA2053E 3551JA2053E COVER ASSEMBLY,DEODORIZER
3551JA1036D 3551JA1036D COVER ASSEMBLY,LOWER
3551JA1025K 3551JA1025K COVER ASSEMBLY,MOTOR
3551JA1101P 3551JA1101P COVER ASSEMBLY,PCB
3551JA2081B 3551JA2081B COVER ASSEMBLY,PTC
3551JA1024A 3551JA1024A COVER ASSY,BACK-M/C
3550JA1172A 3550JA1172A COVER, LAMP
3550JA1077A 3550JA1077A COVER,BANK
3550JD1021G 3550JD1021G COVER,BANK ICE
3550JA1108G 3550JA1108G COVER,HINGE
3550JA1108H 3550JA1108H COVER,HINGE
3550JA1495A 3550JA1495A COVER,LAMP
3550JA2147A 3550JA2147A COVER,MOTOR
3550JA2158A 3550JA2158A COVER,P.T.C
3550JA3095A 3550JA3095A COVER,SENSOR
3550JA2035D 3550JA2035D COVER,SENSOR
3550JA1104B 3550JA1104B COVER,TRAY
3550JA2091A 3550JA2091A COVER,TRAY
3550JA2184B 3550JA2184B COVER,TUBE
3806JA2022F 3806JA2022F DECO,DRAIN
3806JD1021F 3806JD1021F DECO,TRAY
3806JA1027A 3806JA1027A DECO,TRAY
3581JA8377M 3581JA8377M DOOR ASSEMBLY,F
3581JA8375X 3581JA8375X DOOR ASSEMBLY,REFRIGERATOR
5433JA0064S 5433JA0064S DOOR FOAM ASSEMBLY,FREEZER
5433JA0065B 5433JA0065B DOOR FOAM ASSEMBLY,REFRIGERATOR
5251JA3004B 5251JA3004B DRAIN ASSY,PIPE-Z
5851JA2008R 5851JA2008R DRIER ASSEMBLY
ADH73150208 ADH73150208 DRIER ASSEMBLY
5209JA1011D 5209JA1011D DUCT ASSEMBLY, INSULATION
5421JA1124K 5421JA1124K EVAPORATOR ASSEMBLY
5901JA1012A 5901JA1012A FAN ASSEMBLY
5901JA1011A 5901JA1011A FAN ASSEMBLY
ADQ72911006 ADQ72911006 FILTER ASSEMBLY,HEAD
3211JA1007W 3211JA1007W FRAME ASSEMBLY,DISPLAY
3210JA1011J 3210JA1011J FRAME,FUNNEL
4980JA2024H 4980JA2024H FUNNEL
3017JA2001M 3017JA2001M FUNNEL ASSEMBLY
3J02447C 3J02447C FUSE,DRAWING
4987JA1022T 4987JA1022T GASKET ASSEMBLY,DOOR
4987JA1022U 4987JA1022U GASKET ASSEMBLY,DOOR
3531JA2015E 3531JA2015E GRILLE ASSEMBLY,FAN
3531JA2013C 3531JA2013C GRILLE ASSY,FAN
4974JA3028A 4974JA3028A GUIDE
4975JA2012B 4975JA2012B GUIDE ASSY,RAIL
4975JA2003N 4975JA2003N GUIDE ASSY,RAIL
4975JA1012D 4975JA1012D GUIDE ASSY,RAIL
4975JA1012A 4975JA1012A GUIDE ASSY,RAIL
4975JA2003A 4975JA2003A GUIDE ASSY,RAIL
4975JA2012A 4975JA2012A GUIDE ASSY,RAIL
4974JA2055A 4974JA2055A GUIDE,BOTTLE
4974JA1053A 4974JA1053A GUIDE,FAN
4974JA2024A 4974JA2024A GUIDE,RAIL
4974JA2023A 4974JA2023A GUIDE,RAIL
4974JA1043A 4974JA1043A GUIDE,RAIL
4974JA1043B 4974JA1043B GUIDE,RAIL
3650JA0035E 3650JA0035E HANDLE
3650JA2025D 3650JA2025D HANDLE,BACK
3650JA2025R 3650JA2025R HANDLE,BACK
3650JA2023G 3650JA2023G HANDLE,DECO
3650JA2024G 3650JA2024G HANDLE,DECO
3650JA3038A 3650JA3038A HANDLE,PIECE
6877JB3019F 6877JB3019F HARNESS,JOINT
5300JB1092D 5300JB1092D HEATER,SHEATH
4775JA2024A 4775JA2024A HINGE ASSY,U
4930JA3054A 4930JA3054A HOLDER
AEJ73579702 AEJ73579702 HOLDER ASSEMBLY,BRACKET
3806JA2019E 3806JA2019E HOLDER,BUTTON
4930JA3034B 4930JA3034B HOLDER,DRIER
4930JA3043A 4930JA3043A HOLDER,LEVER
4930JA2023B 4930JA2023B HOLDER,SHELF
5989JA1002A 5989JA1002A ICE MAKER ASSY
5988JA1001B 5988JA1001B ICE MAKER(MECH),UNIT
5989JA1002D 5989JA1002D INSULATION
4940JA2008A 4940JA2008A KNOB,SHUTTER
6912JB2004M 6912JB2004M LAMP,INCANDESCENT
6912JK2002E 6912JK2002E LAMP,[INCANDESCENT]
6877JB2039E 6877JB2039E LEAD WIRE ASSY,JOINT
4779JA3001E 4779JA3001E LEG ASSEMBLY,ADJUST
4510JA3007A 4510JA3007A LEVER
4510JA3004A 4510JA3004A LEVER,HINGE
4510JA3003C 4510JA3003C LEVER,ICE MAKER
ADQ72910911 ADQ72910911 LT500P---WATER FILTER CARTRIDGE
3828JD8344X 3828JD8344X MANUAL,OWNERS
4681JB1027B 4681JB1027B MOTOR ASSEMBLY,DC,COOLING
4681JB1029A 4681JB1029A MOTOR ASSEMBLY,REF FAN
4681JB1029B 4681JB1029B MOTOR ASSEMBLY,REF FAN
MFT61843001 MFT61843001 NAME PLATE
MFT62346508 MFT62346508 NAME PLATE
1NZZJA3006A 1NZZJA3006A NUT
CLS30820001 CLS30820001 O.L.P
6748JA3004A 6748JA3004A P.T.C
1PZZJA3013A 1PZZJA3013A PIN,DRAWING
5201JA3011E 5201JA3011E PIPE ASSEMBLY,INJECT
5200JA1009D 5200JA1009D PIPE,JOINT
5200JA1019B 5200JA1019B PIPE,JOINT
6411JB1009B 6411JB1009B POWER CORD ASSY
6871JB1100F 6871JB1100F PWB(PCB) ASSEMBLY,MAIN
2521JA1006B 2521JA1006B RE-COMPRESSOR,ASSEMBLY
5072JA3003F 5072JA3003F RESTRAINER
4580JA3024A 4580JA3024A ROLLER
5040JA2010D 5040JA2010D RUBBER,FUNNEL
5040JA2011A 5040JA2011A RUBBER,INJECT
5040JA2009A 5040JA2009A RUBBER,MOTOR-F
5040JA2009B 5040JA2009B RUBBER,MOTOR-F
5040JA2004A 5040JA2004A RUBBER,MOTOR-F
5040JA3073A 5040JA3073A RUBBER,SEAT
6500JB2004B 6500JB2004B SENSOR
5027JA2041E 5027JA2041E SHELF ASSEMBLY,F
5027JA2036C 5027JA2036C SHELF ASSEMBLY,FREEZER
5027JA2054C 5027JA2054C SHELF ASSEMBLY,NET
5027JA2054B 5027JA2054B SHELF ASSEMBLY,NET
5027JA1013G 5027JA1013G SHELF ASSEMBLY,R
5027JA1013H 5027JA1013H SHELF ASSEMBLY,R
5027JA1035B 5027JA1035B SHELF ASSEMBLY,REFRIGERATOR
4998JA0024A 4998JA0024A SHROUD,F
5070JA3002D 5070JA3002D SKIRT,LOWER
5070JA3002F 5070JA3002F SKIRT,LOWER
5070JA3002J 5070JA3002J SKIRT,LOWER
5070JA3002G 5070JA3002G SKIRT,LOWER
EBE60661303 EBE60661303 SOLENOID ASSEMBLY
6421JA3001D 6421JA3001D SOLENOID ASSY,MAIN
4970JA3011A 4970JA3011A SPRING
4J03277A 4J03277A STOPPER
4621JQ3001G 4621JQ3001G STOPPER ASSEMBLY,DOOR
AJC34211602 AJC34211602 STOPPER ASSEMBLY,DOOR
4621JA3002L 4621JA3002L STOPPER ASSY,DOOR
4980JA2019B 4980JA2019B SUPPORTER,G/M
6600JB3001C 6600JB3001C SWITCH,MICRO
6600JB1010A 6600JB1010A SWITCH,PUSH BUTTON
6600JB3002A 6600JB3002A SWITCH,ROCKER
4838JA1004A 4838JA1004A TANK,WATER
3391JA1032A 3391JA1032A TRAY ASSEMBLY,DRAWER
3391JA1034F 3391JA1034F TRAY ASSEMBLY,SNACK
3391JA1033F 3391JA1033F TRAY ASSEMBLY,VEGETABLE
3391JA1035F 3391JA1035F TRAY ASSEMBLY,VEGETABLE
3391JA2016B 3391JA2016B TRAY ASSY,DRAIN
3390JA1109A 3390JA1109A TRAY,DRIP
3390JA1086A 3390JA1086A TRAY,EGG
3390JA1150A 3390JA1150A TRAY,ICE
3390JD1047F 3390JD1047F TRAY,VEGETABLE
3390JD1048E 3390JD1048E TRAY,VEGETABLE
AJR72929602 AJR72929602 TUBE,PE
5210JA3005A 5210JA3005A TUBE,PE
5210JA3005E 5210JA3005E TUBE,PE
MJU62070602 MJU62070602 TUBE,PE
5210JA3004A 5210JA3004A TUBE,PLASTIC
5221JA2006D 5221JA2006D VALVE ASSEMBLY,WATER
J469-00030A J469-00030A WINE RACK
