Model Image
Manufacturer

LG

Model Number

LUU249HV

Description

24000 Btu 17 Seer High Static Ducted Single Zone H

Interactive Exploded View
Exploded View

Parts List

Part Number Description
DELETE DELETE
4848A20007P 4848A20007P ACCUMULATOR
AAM72909120 AAM72909120 BARRIER ASSEMBLY,OUTDOOR
AAN34062012 AAN34062012 BASE ASSEMBLY,OUTDOOR
ABA74032401 ABA74032401 BRACKET ASSEMBLY,MOTOR(OUTDOOR)
ABQ74980747 ABQ74980747 CASE ASSEMBLY,CONTROL(OUTDOOR)
EAP64467708 EAP64467708 COIL ASSEMBLY,REVERSE
EAP65270704 EAP65270704 COIL MODULE,EXPANSION
EAP63107115 EAP63107115 COIL,EXPANSION
TBZ39215701 TBZ39215701 COMPRESSOR SET,CHINA
TBZ35620301 TBZ35620301 COMPRESSOR SET,KOREA
TBZ37955001 TBZ37955001 COMPRESSOR SET,KOREA
ACG73885401 ACG73885401 CONDENSER ASSEMBLY,BENDING
3A00493K 3A00493K CONNECTOR,TERMINAL BLOCK
EBR36112620 EBR36112620 CONTROL BOARD,INVERTER
EBR36112625 EBR36112625 CONTROL BOARD,INVERTER
EBR36112624 EBR36112624 CONTROL BOARD,INVERTER
EBR36112626 EBR36112626 CONTROL BOARD,INVERTER
EBR36112622 EBR36112622 CONTROL BOARD,INVERTER
EBR36112618 EBR36112618 CONTROL BOARD,INVERTER
EBR36112619 EBR36112619 CONTROL BOARD,INVERTER
MCK39626227 MCK39626227 COVER
MCK39626220 MCK39626220 COVER
ACQ35131832 ACQ35131832 COVER ASSEMBLY,TOP(OUTDOOR)
ACQ35131820 ACQ35131820 COVER ASSEMBLY,TOP(OUTDOOR)
ACQ34583434 ACQ34583434 COVER ASSEMBLY,TUBING
ACQ34583401 ACQ34583401 COVER ASSEMBLY,TUBING
5014A20003A 5014A20003A DAMPER,COMPRESSOR
4H00637A 4H00637A DAMPER,COMPRESSOR
ADP75033301 ADP75033301 FAN ASSEMBLY,PROPELLER
EAF63890201 EAF63890201 FUSE,TIME DELAY
MDX65452401 MDX65452401 GRILLE,DISCHARGE
MDX64291901 MDX64291901 GRILLE,DISCHARGE
MDX61843728 MDX61843728 GRILLE,REAR
MDX61843709 MDX61843709 GRILLE,REAR
EAD62124423 EAD62124423 HARNESS,MULTI
EAD62124417 EAD62124417 HARNESS,MULTI
EAU62543703 EAU62543703 MOTOR ASSEMBLY,DC,OUTDOOR
3A90084A 3A90084A MUFFLER
MFX63082101 MFX63082101 ORIFICE
AGL72770351 AGL72770351 PANEL ASSEMBLY,FRONT(OUTDOOR)
AGL72770336 AGL72770336 PANEL ASSEMBLY,FRONT(OUTDOOR)
AGL76433419 AGL76433419 PANEL ASSEMBLY,REAR(OUTDOOR)
AGL72910401 AGL72910401 PANEL ASSEMBLY,REAR(OUTDOOR)
AGL72909484 AGL72909484 PANEL ASSEMBLY,SIDE
AGL72909316 AGL72909316 PANEL ASSEMBLY,SIDE
AGL72909301 AGL72909301 PANEL ASSEMBLY,SIDE
AGL72909450 AGL72909450 PANEL ASSEMBLY,SIDE
MGC66162402 MGC66162402 PANEL,FRONT
MGC53382919 MGC53382919 PANEL,FRONT
MGC56978351 MGC56978351 PANEL,REAR
EBR84691006 EBR84691006 PCB ASSEMBLY,INVERTER
EBR85059014 EBR85059014 PCB ASSEMBLY,SUB
MKW30000003 MKW30000003 PLUG,FUSIBLE
EBD62165602 EBD62165602 SENSOR,PRESSURE
MDS64011407 MDS64011407 SOUND PROOF
MDS64011501 MDS64011501 SOUND PROOF
MJH39544901 MJH39544901 SUPPORTER
EBG61406003 EBG61406003 THERMISTOR ASSEMBLY,NTC
EBG61106507 EBG61106507 THERMISTOR ASSEMBLY,NTC
EBG61405902 EBG61405902 THERMISTOR ASSEMBLY,NTC
EBG61445812 EBG61445812 THERMISTOR ASSEMBLY,NTC
EBG61106816 EBG61106816 THERMISTOR ASSEMBLY,NTC
EBJ61970010 EBJ61970010 TRANSFORMER,REACTOR
AJR34870216 AJR34870216 TUBE ASSEMBLY,CHECK VALVE
AJR65507622 AJR65507622 TUBE ASSEMBLY,CONDENSER(OUT)
AJR30098302 AJR30098302 TUBE ASSEMBLY,CONNECTOR
5211A20349Z 5211A20349Z TUBE ASSEMBLY,CONNECTOR
AJR73326604 AJR73326604 TUBE ASSEMBLY,MANIFOLD(OUTDOOR)
3H02787N 3H02787N TUBE ASSEMBLY,RETURN BENDING
AJR65521338 AJR65521338 TUBE ASSEMBLY,REVERSE
AJR65507733 AJR65507733 TUBE ASSEMBLY,SUCTION(OUTDOOR)
AAN74512243 AAN74512243 TV STAND ASSEMBLY,OUTDOOR
MJX63992003 MJX63992003 VALVE,EXPANSION BODY
5220AR3228W 5220AR3228W VALVE,REVERSE
2A00671C 2A00671C VALVE,SERVICE
5220A20001J 5220A20001J VALVE,SERVICE
