Model Image
Manufacturer

LG

Model Number

MS60BM

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
3303W1A007A 3303W1A007A BASE PLATE ASSEMBLY
3890W2Y044A 3890W2Y044A BOX,YELLOW
4810W4C003A 4810W4C003A BRACKET,CAPACITOR
4774W3P005A 4774W3P005A BRACKET,HINGE
5020WRG002B 5020WRG002B BUTTON
6908W3YA01C 6908W3YA01C BUZZER,PIEZO
3B73347A 3B73347A CABLE,ASSEMBLY
3B73348D 3B73348D CABLE,ASSEMBLY
0CE1076K638 0CE1076K638 CAPACITOR,AL,RADIAL
0CE1066K638 0CE1066K638 CAPACITOR,AL,RADIAL
0CE1051K638 0CE1051K638 CAPACITOR,AL,RADIAL
0CK2210K518 0CK2210K518 CAPACITOR,CERAMIC,AXIAL
0CK2230K948 0CK2230K948 CAPACITOR,CERAMIC,AXIAL
0CE2271H610 0CE2271H610 CAPACITOR,FIXED ELECTROLYTIC
0CK2230K935 0CK2230K935 CAPACITOR,UNCLASSIFIED
6630W5YA19C 6630W5YA19C CONNECTOR,FFC/FPC/PIC
CQ52212A CQ52212A CONNECTOR,WAFER
CQ52212C CQ52212C CONNECTOR,WAFER
4781W1M049G 4781W1M049G CONTROLLER ASSEMBLY,KEY PAD
3552W1A007A 3552W1A007A COVER,CHOKE
3052W3A015A 3052W3A015A COVER,RESIN
4850W4C001A 4850W4C001A DAMPER
3B72244J 3B72244J DAMPER
0DD400209AA 0DD400209AA DIODE,RECTIFIER
0DD414809AA 0DD414809AA DIODE,SWITCHING
0DD414809AB 0DD414809AB DIODE,SWITCHING
0DZ510009AE 0DZ510009AE DIODE,ZENER
3581W1A054U 3581W1A054U DOOR ASSEMBLY
0CZZW1H002A 0CZZW1H002A DRAWING CAPACITOR
5262W2A017A 5262W2A017A DUCT
5900W1A004A 5900W1A004A FAN,PROPELLER
EAM35001801 EAM35001801 FILTER,AC LINE
4B73900A 4B73900A FOOT
3213W1A009D 3213W1A009D FRAME ASSEMBLY,DOOR
3B70856G 3B70856G FUSE,TIME DELAY
4974W1S010A 4974W1S010A GUIDE,SUCTION
6877W1T187A 6877W1T187A HARNESS
6877W3T080A 6877W3T080A HARNESS,SINGLE
4775W3P004B 4775W3P004B HINGE ASSEMBLY
3501WRA001C 3501WRA001C HOLDER ASSEMBLY,LOCKER
3500WRA001A 3500WRA001A HOLDER,LOCKER
6000W5YB12A 6000W5YB12A IC,DRAWING
6912W3B002K 6912W3B002K LAMP,INCANDESCENT
4510WRA001A 4510WRA001A LEVER
4026WRA001A 4026WRA001A LOCKER
2B71732F 2B71732F MAGNETRON
3828W5A0119 3828W5A0119 MANUAL,OWNERS
6638W2A034A 6638W2A034A MEMBRANE
6549W1S013A 6549W1S013A MOTOR, AC SYNCHRONOUS
2B73670B 2B73670B MOTOR,AC FAN
3112W1A001B 3112W1A001B OUT CASE,U-BENDING
3572W1A067B 3572W1A067B PANEL,CONTROL
3302W1A006A 3302W1A006A PLATE,BASE
6411W2A002A 6411W2A002A POWER CORD ASSEMBLY
5247W2YJ70A 5247W2YJ70A PWB(PCB) ASSEMBLY,SUB
6920WRD005B 6920WRD005B RELAY,CONTACT
6920WRD004A 6920WRD004A RELAY,CONTACT
0RD4702G608 0RD4702G608 RESISTOR,CARBON FILM
0RD4702F608 0RD4702F608 RESISTOR,CARBON FILM
0RD1004F608 0RD1004F608 RESISTOR,CARBON FILM
0RD3901F608 0RD3901F608 RESISTOR,CARBON FILM
0RD1003F608 0RD1003F608 RESISTOR,CARBON FILM
0RD1002F608 0RD1002F608 RESISTOR,CARBON FILM
0RD1201F608 0RD1201F608 RESISTOR,CARBON FILM
0RD2701F608 0RD2701F608 RESISTOR,CARBON FILM
0RD2202G608 0RD2202G608 RESISTOR,CARBON FILM
0RD1001G608 0RD1001G608 RESISTOR,CARBON FILM
0RD2202F608 0RD2202F608 RESISTOR,CARBON FILM
0RD1001F608 0RD1001F608 RESISTOR,CARBON FILM
4B70188C 4B70188C SCREW,CUSTOMIZED
1TTL0403818 1TTL0403818 SCREW,TAPPING
1TTL0402818 1TTL0402818 SCREW,TAPPING
1TTL0402418 1TTL0402418 SCREW,TAPPING
1SBF0402618 1SBF0402618 SCREW,TAPTITE
1TTG0402422 1TTG0402422 SCREW,TAPTITE
4370WRT001C 4370WRT001C SHAFT,TURNTABLE
4B72023A 4B72023A SPRING
4970WRA001A 4970WRA001A SPRING
3B73362A 3B73362A SWITCH,MICRO
6600W1K001C 6600W1K001C SWITCH,MICRO
3B73362F 3B73362F SWITCH,MICRO
3536WRA001F 3536WRA001F TAPE,SEALING
6930WRT001G 6930WRT001G THERMOSTAT
0TR107009AE 0TR107009AE TR,BIPOLAR
0TR107009AD 0TR107009AD TR,BIPOLAR
0TR126609AA 0TR126609AA TR,BIPOLAR
6010WRH005A 6010WRH005A TRANSFORMER,HIGH VOLTAGE
6010W2P037A 6010W2P037A TRANSFORMER,POWER
0TR319809AA 0TR319809AA TRANSISTOR
2B71852A 2B71852A TRAY,GLASS
5889W2A005B 5889W2A005B TURNTABLE ASSEMBLY
3352W1A028P 3352W1A028P WINDOW,SCREEN
