Model Image
Manufacturer

LG

Model Number

MV1648ADL

Description

Mv1648adl

Interactive Exploded View

Parts List

Part Number Description
MAE41907001 MAE41907001 BAFFLE [1011]
MAY56733608 MAY56733608 BOX [01-MAY]
4810W1A313A 4810W1A313A BRACKET,CAPACITOR [5002]
MAZ41908501 MAZ41908501 BRACKET,CONTROL PANEL [2008]
4810W1A151A 4810W1A151A BRACKET,IDLE [6010]
4810W1A150D 4810W1A150D BRACKET,LAMP [3025]
4811W1A008B 4811W1A008B BRACKET,MOUNT [3029]
4810W1A305B 4810W1A305B BRACKET,THERMOSTAT [5067]
6021W3B001V 6021W3B001V CABLE,ASSEMBLY [5018]
0CZZW1M001C 0CZZW1M001C CAPACITOR,FILM,BOX [2018]
0CZZW1H004B 0CZZW1H004B CAPACITOR,HIGH VOLTAGE [5000]
3840W1T006F 3840W1T006F CARD,TECHNICAL [MBM2]
4922W5A057B 4922W5A057B CARD,TEMPLATE [MBM4]
4922W5A060B 4922W5A060B CARD,TEMPLATE [MBM5]
3112W1F056S 3112W1F056S CASE,U BENDING [3001]
ACM49437012 ACM49437012 CONTROLLER ASSEMBLY,KEYPAD [2004]
3552W1A032J 3552W1A032J COVER,CHOKE [1004]
3550W1A190C 3550W1A190C COVER,LAMP [5036]
3550W1A189A 3550W1A189A COVER,LAMP [5045]
3052W1A002A 3052W1A002A COVER,RESIN [3034]
3550W1A126D 3550W1A126D COVER,STIRRER FAN [5044]
4900W1A001B 4900W1A001B DAMPER [6011]
ADC49436906 ADC49436906 DOOR ASSEMBLY [1005]
5208W0A006C 5208W0A006C DUCT [5006]
5893W3A002D 5893W3A002D FAN ASSEMBLY [5024]
EAM35001801 EAM35001801 FILTER,AC LINE [5041]
5230W1A011B 5230W1A011B FILTER,CHARCOAL [5037]
5230W1A012B 5230W1A012B FILTER,GREASE [3026]
3213W1A049F 3213W1A049F FRAME ASSEMBLY,DOOR [1000]
3B74133Q 3B74133Q FUSE,TIME DELAY [5001]
AEB49577101 AEB49577101 GRILLE ASSEMBLY [3038]
MEB41909001 MEB41909001 HANDLE,DOOR [1009]
6877W1A597N 6877W1A597N HARNESS,SINGLE [5014]
3501W1A019D 3501W1A019D HOLDER ASSEMBLY,LOCKER [4001]
4930W1A069A 4930W1A069A HOLDER,COOK AUXILIARY [3036]
3500W1A028B 3500W1A028B HOLDER,LOCKER [4000]
3861W1A043A 3861W1A043A KIT ASSEMBLY [6009]
3850W1D069G 3850W1D069G LABEL,COOKING GUIDE [MEZ1]
6620G00007B 6620G00007B LAMP HOLDER [5038]
6912W1Z004C 6912W1Z004C LAMP,INCANDESCENT [3028]
4510W3A012C 4510W3A012C LEVER [4004]
4026W2A015A 4026W2A015A LOCKER [1006]
2B71165R 2B71165R MAGNETRON [5009]
6549W1S013K 6549W1S013K MOTOR, AC SYNCHRONOUS [3009]
6549W1V006Y 6549W1V006Y MOTOR, AC VENTILATION [3027]
AGM55833803 AGM55833803 PARTS ASSEMBLY [1381]
ACM49437101 ACM49437101 PARTS ASSEMBLY [2381]
3303W1A072L 3303W1A072L PLATE ASSEMBLY,BASE [6001]
4960W1A022B 4960W1A022B PLATE [3010]
3302W0A047H 3302W0A047H PLATE,BASE [6000]
3300W1A003D 3300W1A003D PLATE,BOTTOM [5034]
3300W1A045C 3300W1A045C PLATE,BOTTOM [5035]
3300W0A030A 3300W0A030A PLATE,MOUNT [6008]
6411W1A019M 6411W1A019M POWER CORD ASSEMBLY [5010]
4B70188C 4B70188C SCREW,CUSTOMIZED [W102]
1TTL0402418 1TTL0402418 SCREW,TAPPING [W105]
1TTL0402818 1TTL0402818 SCREW,TAPPING [W106]
1TTL0402416 1TTL0402416 SCREW,TAPPING [W107]
1TPL0402618 1TPL0402618 SCREW,TAPPING [W130]
1TTG0402416 1TTG0402416 SCREW,TAPPING [W175]
1TTL0402816 1TTL0402816 SCREW,TAPPING[TRUSS HEAD] [W142]
1SBF0402418 1SBF0402418 SCREW,TAPTITE [W101]
4370W1A006B 4370W1A006B SHAFT,TURNTABLE [3012]
5026W1A048C 5026W1A048C SHELF [3018]
4970WRA001B 4970WRA001B SPRING [1007]
3740W1A005E 3740W1A005E SUPPORTER [3037]
3740W1A011B 3740W1A011B SUPPORTER [5337]
3B73362F 3B73362F SWITCH,MICRO [4002]
3B73361E 3B73361E SWITCH,MICRO [4003]
3536W1A012B 3536W1A012B TAPE,SEALING [1002]
6930W1A003E 6930W1A003E THERMOSTAT [5016]
6170W1D052U 6170W1D052U TRANSFORMER,HIGH VOLTAGE [5008]
1B71961E 1B71961E TRAY,GLASS [3002]
5889W2A012F 5889W2A012F TURNTABLE ASSEMBLY [3008]
MKC42429704 MKC42429704 WINDOW,GLASS [1008]
4890W1A045A 4890W1A045A WINDOW,GLASS [3011]
